10. Connect the camera to the computer using the USB cable.

11. Import the images into FLIR Tools/Tools+ or FLIR Report Studio and create

an inspection report.

12. Send the inspection report to your client.

3.7 View from the front

See Figure 2.1 View from the front, page 2.

1. Autofocus button.

2. Save button.

3. Viewfinder.

4. Knob to change the dioptric correction for the viewfinder.

5. Attachment point for the neck strap.

6. Laser receiver.

7. Laser transmitter.

8. Camera lamp (left and right sides).

9. Infrared lens.

10. Digital camera.

3.8 View from the rear

See Figure 2.2 View from the rear, page 3.

1. Focus ring.

2. Speaker.

3. Programmable button.

4. Image archive button.

5. Navigation pad with center push.

6. Back button.

7. On/off button.

8. Hand strap.

9. Multi-touch LCD screen.

10. Light sensor.

11. Microphone.

12. Attachment point for the neck strap.

3.9 View from the bottom

See Figure 2.3 View from the bottom, page 3.

1. Laser button.

2. Programmable button.
