FLIR DM284: Imaging Multimeter with IGM

P/N: DM284

#DM284; r. /42563;

Thermal imaging

Thermal sensitivity 150 mK

IR image capture frequency 9 Hz

IR image color palettes

Rainbow, Iron, Gray scale

Laser pointer type Class I (red)

Laser pointer power <0.4 mW

IR temperature measurement range

–10 to 150°C (14 to 302°F)

Over- and under-range indication OL

Temperature reading stabilization Dashes are displayed for approximately 30

seconds as the temperature reading stabilizes

IR temperature resolution 0.1°C (0.1°F)

IR temperature accuracy ±3°C (5.4°F) or ± 3% of the reading (whichever is

greater) for >25°C (77°F), ±5°C –10°C to 25°C

(14°F to 77°F)

Distance-to-spot (D:S) ratio

30:1

Emissivity adjustment 0.95 maximum, 4 presets plus a custom setting

(0.10–0.99)

Targeting Displayed cross-hairs pinpoint the center of the

measurement spot

Hold Image with measurement

Electrical measurement

Maximum voltage

1000 V DC or 1000 V AC RMS

Display count 6000

Frequency counter

• 100.00 Hz ± (0.1% + 2D)

• 1000.0 Hz ± (0.1% + 2D)

• 10.000 kHz ± (0.1% + 2D)

• 100.00 kHz ± (0.1% + 2D)

Resistance

• 600.0 Ω ± (0.9% + 5D)

• 6.000 kΩ ± (0.9% + 2D)

• 60.00 kΩ ± (0.9% + 2D)

• 600.0 kΩ ± (0.9% + 2D)

• 6.000 MΩ ± (0.9% + 2D)

• 50.00 MΩ ± (3.0% + 5D)

Continuity check 600.0 Ω ± (0.9% + 5D)

Diode test 1.500 ± (0.9% + 2D)

Capacitance

• 1000 nF ± (1.9% + 5D)

• 10.00 µF ± (1.9% + 2 digits)

• 100.0 µF ± (0.9% + 2 digits)

• 1.000 mF ± (0.9% + 2 digits)

• 10.00 mF ± (0.9% + 2 digits)

• 40.00 mF ± (2.0% + 20 digits)

Temperature, type K thermocouple

• –40 to 752.0°F DMM ± (1.0% + 5.4°F)/ IGM ±

(1.0% + 9°F)

• –40 to 400°C DMM ± (1.0% + 3°C)/ IGM ±

(1.0% + 5°C)

Measuring rate 3 samples per second

Meter data

Category rating CAT IV—600 V, CAT III—1000 V

IP rating IP54

Drop test 3M
