Husqvarna LC247i, без аккум и ЗУ [21/572] Control panel

Control panel

Keypad Error code (Num-

ber of flashes)

Possible faults Possible action

Error LED flashes 3 The motor is overloaded Increase the cutting height. Refer to

set the cutting height on page 17

5 The motor speed drops too

much, and the motor stops

10 The motor control is too hot Stop the motor and wait until it has be-

come cool

2 The blade is blocked To prevent accidental start turn the safe-

ty key to 0, remove the battery and wait

a minimum 5 seconds. Make sure that

the blade can rotate freely. If the prob-

lem continues, speak to an authorised

service agent

9 Battery error or no signal from

battery

Put the battery in the product correctly

and examine the battery connector. If the

error LED on the battery flashes. Refer

Battery on page 17

The product stops 8 The battery is weak Charge the battery. Refer to

To charge

the battery on page 17

0 Battery connector failure Examine the battery connector

Other errors If other errors occur, turn the safety key to 0, remove the battery and speak to an approved

service agent.

Transportation, storage and disposal

Introduction

WARNING: To prevent unintentional start

during transport turn the safety key to ”0”,

remove the battery and wait at least 5

seconds.

To set the product in transport position

1. Loosen the lower knobs.

2. Move the knobs to the lower end of the grooves on

the left and the right side of the product. (Fig. 26)

3. Fold the handle forward. (Fig. 49)

4. Remove the grass catcher.

Transportation

• The Dangerous Goods Legislation requirements

apply to the contained Li-ion batteries.

• For commercial transports special requirements on

package and labels must be obeyed.

• Make sure that you obey the regulations for

dangerous material when you prepare the product

for transport. Local regulations can apply.

• Always remove the battery for transport.

• Put tape on the battery connectors and make sure

that the battery cannot move around during

transport.

• Attach the product during transport.

Storage

• Always remove the battery for storage.

• To prevent accidents, make sure that the battery is

not connected to the product during storage.

• Keep the battery charger in a closed and dry space.

• Keep the battery and the battery charger in a dry

space where there is no moisture or frost.

• Disconnect the battery from the battery charger

during storage.

• Do not keep the battery where static electricity can

occur. Do not keep the battery in a metal box.

• Keep the battery where the temperature is between

5°C and 25°C and out of sunlight.

• Keep the battery charger where the temperature is

between 5°C and 45°C and out of sunlight.

• Make sure that the battery is charged to 30% - 50%

before you put it in storage for long periods.

1199 - 002 - 21.11.2019 21
