Bosch GSR 18V-60 FC Flex (06019G7101) [19/253] After sales service and advice on using products

English | 19

You can preselect two speed ranges with the gear selector

(4).

First gear:

Low speed range; for working with a large drilling diameter

or for screwdriving.

Second gear:

High speed range; for working with a small drilling diameter.

u Always push the gear selector switch as far as it will

go. Otherwise, the power tool may become damaged.

Switching on/off

To start the power tool, press and hold the on/off switch

(10).

The worklight (8) lights up when the on/off switch (10) is

lightly or fully pressed, allowing the work area to be illumin-

ated in poor lighting conditions.

The worklight (8) will remain lit for approximately ten

seconds after the on/off switch (10) has been released.

Adjusting the Speed

You can adjust the speed of the power tool when it is on by

pressing in the on/off switch (10) to varying extents.

A light pressure on the on/off switch (10) results in a low ro-

tational speed. Increased pressure on the switch causes an

increase in speed.

Fully automatic spindle lock (Auto-Lock)

The drill spindle, and therefore the mounting (1), are locked

when the on/off switch (10) is not pressed.

This allows screws to be driven in even when the battery is

discharged and enables the power tool to be used as a

screwdriver.

Temperature-dependent overload protection

In normal conditions of use, the power tool cannot be over-

loaded. If the power tool is overloaded or not kept within the

permitted battery temperature range, the power output is

reduced or the power tool is switched off. The power tool

will not run at full power output again until the permitted bat-

tery temperature has been reached.

Connectivity functions

In conjunction with the GCY 30-4 Bluetooth

Low Energy

Module, the following connectivity functions are available for

the power tool:

– Registration and personalisation

– Status check, output of warning messages

– General information and settings

– Management

Read the corresponding operating instructions for informa-

tion about the GCY30-4 Bluetooth

Low Energy Module.

Battery charge indicator (battery model GBA18V...)

(see figure A)

The three green LEDs of the battery charge indicator (18) in-

dicate the state of charge of the battery (6). For safety reas-

ons, it is only possible to check the state of charge when the

power tool has been stopped.

Press the button (19) to show the state of charge. This is

also possible when the battery is removed.

LEDs Capacity

3 × continuous green light ≥ 66%

2 × continuous green light ≥ 33%

1 × continuous green light <33%

1 × flashing green light Reserve

If no LED lights up after pressing the button (19), then the

battery is defective and must be replaced.

Practical advice

u With the GCY 30-4 Bluetooth

Low Energy Module, the

power tool is equipped with a radio interface. Local

operating restrictions, e.g. in aircraft or hospitals,

must be observed.

u Only apply the power tool to the screw/nut when the

tool is switched off. Rotating tool inserts can slip off.

After working at a low speed for an extended period, you

should operate the power tool at the maximum speed for ap-

proximately three minutes without load to cool it down.

When drilling into metal, only use sharpened HSS drills (HSS

= high-speed steel) which are in perfect condition. The

Bosch accessory range guarantees appropriate quality.

Before screwing larger, longer screws into hard materials, it

is advisable to pre-drill a pilot hole with the core diameter of

the thread to approx. 2/3 of the screw length.

Maintenance and Servicing

Maintenance and Cleaning

u Remove the battery from the power tool before carry-

ing out work on the power tool (e.g. maintenance,

changing tool, etc.). The battery should also be re-

moved for transport and storage. There is risk of injury

from unintentionally pressing the on/off switch.

u To ensure safe and efficient operation, always keep

the power tool and the ventilation slots clean.

After-sales service and advice on using products

Our after-sales service responds to your questions concern-

ing maintenance and repair of your product as well as spare

parts. You can find explosion drawings and information on

spare parts at: www.bosch-pt.com

The Bosch product use advice team will be happy to help you

with any questions about our products and their accessor-

ies.

In all correspondence and spare parts orders, please always

include the 10‑digit article number given on the nameplate

of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)

P.O. Box 98

Broadwater Park

North Orbital Road

Bosch Power Tools 1 609 92A 4RU | (31.10.2018)
