Dewalt DCD996P2 [13/16] Forward reverse control button fig a

English

Variable Speed Switch (Fig. A)

To turn the tool on, squeeze the trigger switch

1

. To turn the

tool off, release the trigger switch. Your tool is equipped with

a brake. The chuck will stop as soon as the trigger switch is

fullyreleased.

nOTE: Continuous use in variable speed range is not

recommended. It may damage the switch and should

beavoided.

Side Handle (Fig. A)



WARNING: To reduce the risk of personal injury, ALWAYS

operate the tool with the side handle properly installed.

Failure to do so may result in the side handle slipping

during tool operation and subsequent loss of control. Hold

tool with both hands to maximize control.

The side handle

7

clamps to the front of the gear case and may

be rotated 360˚ to permit right- or left-hand use. Side handle

must be tightened sufficiently to resist the twisting action of

the tool if the accessory binds or stalls. Be sure to grip the side

handle at the far end to control the tool during astall.

If model is not equipped with side handle, grip drill with one

hand on the handle and one hand on the battery pack.

nOTE: Side handle comes equipped on all models.

Forward/Reverse Control Button (Fig. A)

A forward/reverse control button

2

determines the direction of

the tool and also serves as a lock off button.

To select forward rotation, release the trigger switch and

depress the for ward/re verse control button on the right side of

the tool.

To select reverse, release the trigger switch and depress the

forward/reverse control button on the left side of the tool.

The center position of the control button locks the tool in the off

position. When changing the position of the control button, be

sure the trigger is released.

nOTE: The first time the tool is run after changing the direction

of rotation, you may hear a click on start up. This is normal and

does not indicate a problem.

Torque Adjustment Collar/Electronic Clutch

(Fig. C–E)

Your tool has an electronic adjustable torque screwdriver

mechanism for driving and removing a wide array of fasteners.

Circling the torque adjustment collar

5

are numbers. These

numbers are used to set the clutch to deliver a torque range.

The higher the number on the collar, the higher the torque and

the larger the fastener which can be driven. To select any of the

numbers, rotate until the desired number aligns with the arrow.

Three-Speed Gearing (Fig. A, C–E)

The three-speed feature of your tool allows you to shift gears

for greater versatility. To select speed 1 (highest torque setting),

turn the tool off and permit it to stop. Slide the gear shifter

6

all the way forward. Speed 2 (middle torque and speed setting)

is in the middle position. Speed 3 (highest speed setting) is to

the rear.

nOTE: Do not change gears when the tool is running. Always

allow the drill to come to a complete stop before changing

gears. If you have trouble changing gears, make sure that the

gear shifter is engaged in one of the three speed settings.

If the speed shifter becomes stuck or is difficult to select the

desired gear, pull the trigger switch

1

to rotate the motor. Then

select the gear.

Keyless Single Sleeve Chuck (Fig. F–H)



WARNING: Do not attempt to tighten drill bits (or

any other accessory) by gripping the front part of the

chuck and turning the tool on. Damage to the chuck

and personal injury may result. Always lock off trigger

switch and disconnect tool from power source when

changingacces sories.



WARNING: Always ensure the bit is secure before starting

the tool. A loose bit may eject from tool causing possible

personal injury.

Your tool features a keyless chuck with one rotating sleeve for

one-handed operation of the chuck. To insert a drill bit or other

accessory, follow these steps.

1. Turn off tool and disconnect tool from power source.

2. Grasp the black sleeve of the chuck

4

with one hand and

use the other hand to secure the tool as shown in FigureF.

Rotate the sleeve counterclockwise (as viewed from the

front) far enough to accept the desired accessory.

3. Insert the accessory about 19 mm into the chuck (Fig.G).

Tighten securely by rotating the chuck sleeve clockwise

with one hand while holding the tool with the other hand

(Fig.H). Continue to rotate the chuck sleeve until several

ratchet clicks are heard to ensure full gripping power.

To release the accessory, repeat Steps 1 and 2 above.

Be sure to tighten chuck with one hand on the chuck sleeve and

one hand holding the tool for maximum tightness.

LED Worklight (Fig. A)

The LED worklight

3

and its worklight switch

13

are located on

the foot of the tool. The worklight is activated when the trigger

switch is depressed. The low

14

, medium

15

and spotlight

16

modes can be changed by moving the switch on the foot of the

tool. If the trigger switch remains depressed, the worklight will

remain on in all modes.

When on low

14

and medium

15

settings, the beam will

automatically turn off 20 seconds after the trigger switch

isreleased.

Spotlight Mode

The high setting

16

is the spotlight mode. The spotlight will

run for 20 minutes after the trigger switch is released. Two

minutes before the spotlight will shut off, it will flash twice and

then dim. To avoid the spotlight shutting off, lightly tap the

trigger switch.



WARNING: While using the worklight in medium or

spotlight mode, do not stare at the light or place the drill in

a position which may cause anyone to stare into the light.

Serious eye injury could result.
