12
English
CAUTION: When using the tool as a spotlight, be sure
it is secured on a stable surface where it will not cause a
tripping or falling hazard.
CAUTION: Remove all accessories from the chuck before
using the drill as a spotlight. Personal injury or property
damage could result.
Low Battery Warning
When in spotlight mode and the battery is nearing complete
discharge, the spotlight will flash twice and then dim. After two
minutes, the battery will be completely discharged and the
drill will immediately shut down. At this point, replace with a
charged battery.
WARNING: To reduce the risk of injury, always have a
back-up battery or secondary lighting available if the
situation warrants it.
Belt Hook and Magnetic Bit Holder (Fig. A)
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.
WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool’s belt hook
from a work belt.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook is secure.
CAUTION: To reduce the risk of personal injury or
damage, DO NOT use the belt hook to hang the drill
while using as a spotlight.
iMPORTAnT: When attaching or replacing the belt hook or
magnetic bit holder, use only the screw
11
that is provided. Be
sure to securely tighten the screw.
The belt hook
10
and magnetic bit holder
12
can be be
attached to either side of the tool using only the screw
11
provided, to accommodate left- or right- handed users. If the
hook or magnetic bit holder is not desired at all, it can be
removed from the tool.
To move belt hook or magnetic bit holder, remove the screw
11
that holds it in place then reassemble on the opposite side.
Be sure to securely tighten the screw.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. I)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown infigureI.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle
18
, with the other hand on the side handle
7
.
Drill Operation (Fig. D)
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories.
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood “back-
up” block to prevent damage to the material.
1. Select the desired speed/torque range using the gear shifter
to match the speed and torque to the planned operation.
Set the torque adjustment collar
5
to the drill symbol.
2. For Wood, use twist bits, spade bits, power auger bits or
hole saws. For Metal, use high-speed steel twist drill bits
or hole saws. Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass which should be
drilleddry.
3. Always apply pressure in a straight line with the bit. Use
enough pressure to keep the drill bit biting, but do not push
hard enough to stall the motor or deflect the bit.
4. Hold tool firmly with both hands to control the twisting
action of the drill.
5. iF DRill sTAlls, it is usually because it is being
overloaded. RElEAsE TRiggER iMMEDiATElY, remove
drill bit from work, and determine cause of stalling. DO nOT
CliCK TRiggER OFF AnD On in An ATTEMPT TO sTART
A sTAllED DRill – This CAn DAMAgE ThE DRill.
6. Keep the motor running when pulling the bit back out of a
drilled hole. This will help prevent jamming.
Screwdriver Operation (Fig. C)
1. Select the desired speed/torque range using the three-
speed gear shifter
6
on the top of the tool. If using the
torque adjustment collar
5
, initially set the three-speed
gear shifter to speed 2 or 3. This ensures effective control
over the fastener allowing the screw to be seated correctly
and set to specification. Speed 1 will provide the same
clutching torque as speeds 2 and 3. However, for optimum
performance of the electronic clutch, speeds 2 and 3
arepreferred.
nOTE: Use the lowest torque setting (1) first and increase
the number through to the highest setting (11) to seat the
fastener at the desired depth. The lower the number, the
lower the torque output.
2. Reset the torque adjustment collar
5
to the appropriate
number setting for the torque desired. Make a few practice
runs in scrap or unseen areas to determine the proper
position of the torque adjustment collar.
nOTE: The torque adjustment collar may be set to any number
at any time.
