ENGLISH en
11
The correct setting is found by trial and error.
Example: if work is being completed on soft, brittle
material or if you want to keep breakage to a low
level, work at “reduced impact force”.
Use the “maximum impact force” setting for working
with harder materials.
7.5 Switching on and off
Torque setting:
Press the trigger switch (9) to switch on the
machine.
To switch off release the trigger switch (9).
Continuous operation (only in chiselling
mode ):
The machine can be switched to continuous
operation (only in chiselling mode ) by pressing
the (10) button. ( (10) button illuminated.)
To switch off, press the (10) button once again. (
(10) button not illuminated.)
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore, always hold the machine with
both hands using the handles provided, stand
securely and concentrate.
7.6 Metabo VibraTech (MVT)
For reduced vibrations and less stress on the
hands.
Always apply a moderate amount of pressure to the
handle when pushing down the machine and do not
force. Vibrations are reduced most effectively at the
central position (8).
The power tool should be cleaned regularly, often
and thoroughly through all air vents using a vacuum
cleaner or by blowing in dry air. Prior to this
operation, separate the power tool from the power
source and wear protective glasses and dust mask.
Elektronic signal indicator (12)
Flashing - restart protection
When power is restored after a power failure,
the machine - which is still switched on - will
not start for safety reasons. Switch machine on and
off again.
Continuously illuminated - overload
If the machine is overloaded for a long period
of time, the power intake is limited to avoid
further excessive heating of the motor.
Allow the machine to run at idle speed until it has
cooled off and the electronic signal indicator goes
out.
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
See page 4.
A Extensive drill bit and chisel assortment for a
wide range of applications.
B Special grease (for lubricating the tool shanks)
C Dust extraction system
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be carried out
by qualified electricians!
The connection cable must only be replaced by
Metabo or an authorised customer service
workshop.
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: never dispose of
power tools in your household waste! Used
power tools must be collected separately and
handed in for environmentally compatible recycling
in accordance with European Directive 2002/96/EC
on waste electrical and electronic equipment and its
implementation in national legal systems.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
P
1
=Rated input power
P
2
=Power output
n
0
=No-load speed
D
1
=Max. drilling diameter in concrete with
impact masonry bits
D
2
=Max. drilling diameter in concrete with
impact core cutters
s
max
=Maximum impact rate
W=Single impact force
C=Number of chisel positions
m =Weight without mains cable
Measured values determined in conformity with
EN 60745.
Machine in protection class II
~ AC power
The technical specifications quoted are subject to
tolerances (in compliance with relevant valid
standards).
Emission values
8. Cleaning, Maintenance
9. Troubleshooting
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical Specifications
