13 ENGLISH
Installing the guard
WARNING: Never use the tool without the
guard illustrated in place.Failuretodosocan
causeseriouspersonalinjury.
CAUTION: Take care not to injure yourself on
the cutter for cutting the nylon cord.
►Fig.16
1. Aligntheprojectionsontheprotectorwiththe
grooves of the motor housing.
►Fig.17: 1. Protector 2.Projection3. Groove
2. Aligntheprojectionsontheprotectorholderwith
its counter parts of the motor housing.
►Fig.18: 1. Protector holder 2.Projection
3. Tightenthehexboltssecurelytofastentheprotec-
tor and the protector holder.
►Fig.19: 1.Hexbolt
Installing the wire guard
CAUTION: Before adjusting the wire guard,
wait for the cutting head comes to standstill. Do
not adjust the wire guard with your foot.
►Fig.20
Toreducetheriskdamagingtheobjectsinfrontofthe
cutting head, insert the wire guard so that it controls the
cutting range of the mowing line.
Slightlyexpandthewireguardoutwardandtheninsert
it into the holes of the protector.
►Fig.21: 1.Wireguard
NOTE:Donotexpandthewireguardoutwardtoo
much. Otherwise it may break.
Whenwireguardisnotinuse,liftitfortheidleposition.
►Fig.22
Installing nylon cutting head
Optional accessory
CAUTION: If the nylon cutting head acciden-
tally impacts a rock or hard object during oper-
ation, stop the tool and inspect for any damage.
If the nylon cutting head is damaged, replace it
immediately. Use of a damaged cutting tool could
resultinseriouspersonalinjury.
CAUTION: Make sure to remove the hex
wrench after installation.
NOTICE: Be sure to use genuine Makita nylon
cutting head.
1. Turn the tool upside down so that you can replace
the cutting tool easily.
2. Insertthehexwrenchthroughtheholeonthe
motor housing and rotate the receive washer until it is
lockedwiththehexwrench.
3. Place the nylon cutting head onto the threaded
spindle directly and tighten it by turning it clockwise.
4. Removethehexwrench.
To remove the nylon cutting head, turn it counterclock-
wisewhileholdingthereceivewasherwiththehex
wrench.
►Fig.23: 1. Nylon cutting head 2. Metal guard
3. Receive washer 4.Hexwrench
OPERATION
Correct handling of tool
WARNING: Always position the tool on your
right-hand side. Correct positioning of the tool allows
formaximumcontrolandwillreducetheriskofseri-
ouspersonalinjurycausedbykickback.
WARNING: Be extremely careful to maintain
control of the tool at all times. Do not allow the
tool to be deected toward you or anyone in the
work vicinity.Failuretokeepcontrolofthetool
couldresultinseriousinjurytothebystanderandthe
operator.
►Fig.24
Attachment of shoulder harness
CAUTION: Always use the shoulder harness
attached. Before operation, adjust the shoulder
harness according to the user size to prevent
fatigue.
Connect the clasp of the shoulder harness to the hook
part of the housing. Put the shoulder harness on. Be
sure that the buckles are locked completely in place.
►Fig.25: 1. Buckle 2. Hook
Detachment
The buckle is provided with a means of quick release.
Simplysqueezethesidesofthebuckletoreleasethe
tool.
►Fig.26: 1. Buckle
MAINTENANCE
WARNING: Always be sure that the tool is
switched off and battery cartridge is removed
before attempting to perform inspection or main-
tenance on the tool.Failuretoswitchoffandremove
the battery cartridge may result in serious personal
injuryfromaccidentalstart-up.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
