14 ENGLISH
Replacing the nylon cord
WARNING: Use nylon cord with diameter
specied in “SPECIFICATIONS” only. Never use
heavier line, metal wire, rope or the like. Use rec-
ommended nylon cord only, otherwise it may cause
damage to the tool and result in serious personal
injury.
WARNING: Make sure that the cover of the
nylon cutting head is secured to the housing
properly as described below.Failuretoproperly
secure the cover may cause the nylon cutting head to
yapartresultinginseriouspersonalinjury.
1. Take off the cover from the housing, pressing two
latches which are slotted section oppositely on the side
of the housing.
►Fig.27
2. Cutanylonlinein3m(10ft).Foldthecuttingline
in two halves, leave one of half longer 80-100 mm (3 - 4
inches) than another.
►Fig.28
3. Hook the middle of the new nylon cord to the
notch located at the center of the spool between the 2
channels provided for the nylon cord.
Windbothendsrmlyaroundthespoolinthedirection
marked on the head for right hand direction indicated
by RH.
►Fig.29
4. Windallbutabout100mm(4”)ofthecords,leav-
ing the ends temporarily hooked through a notch on the
side of the spool.
►Fig.30
5. Mount the spool on the cover so that the grooves
and protrusions on the spool match up with those on the
cover. Now, unhook the ends of the cord from their tem-
porary position and feed the cords through the eyelets
to come out of the cover.
►Fig.31
6. Align the protrusion on the underside of the cover
withtheslotsoftheeyelets.Thenpushthecoverrmly
onto the housing to secure it. Make sure the latches
fully spread in the cover.
►Fig.32
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers, always using Makita replacement parts.
TROUBLE SHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
ment parts for repairs.
State of abnormality Probable cause (malfunction) Remedy
Motor does not run. Battery cartridge is not installed. Install the battery cartridge.
Battery problem (under voltage) Recharge the battery. If recharging is not effective,
replace battery.
The drive system does not work
correctly.
Ask your local authorized service center for repair.
Motor stops running after a little use. Battery's charge level is low. Recharge the battery. If recharging is not effective,
replace battery.
Overheating. Stopusingoftooltoallowittocooldown.
ItdoesnotreachmaximumRPM. Battery is installed improperly. Install the battery cartridge as described in this
manual.
Battery power is dropping. Recharge the battery. If recharging is not effective,
replace battery.
The drive system does not work
correctly.
Ask your local authorized service center for repair.
Cutting tool does not rotate:
stop the machine immediately!
Foreignobjectsuchasabranchis
jammedbetweentheguardandthe
nylon cutting head.
Removetheforeignobject.
The drive system does not work
correctly.
Ask your local authorized service center for repair.
Abnormal vibration:
stop the machine immediately!
One end of the nylon cord has been
broken.
Tap the nylon cutting head against the ground while
it is rotating to cause the cord to feed.
The drive system does not work
correctly.
Ask your local authorized service center for repair.
Cutting tool and motor cannot stop:
Remove the battery immediately!
Electricorelectronicmalfunction. Remove the battery and ask your local authorized
service center for repair.
