2 in 1 Grass Trimmer/Edger EN
1110
tighten completely until you have adjusted
the auxiliary handle to your desired
working position.
3. ADJUSTING AUXILIARY HANDLE
(See Fig. C2)
1) The auxiliary handle’s bracket can be
moved up or down on the shaft and the
auxiliary handle itself can be moved
forward or backward into 4 different locked
positions (See Fig.C2).
2) When the handle is in desired position, turn
knob and tighten securely.
4. ADJUST THE HEIGHT (See Fig. D1, D2)
The Trimmer’s Telescopic Shaft comes in the
Collapsed Position
1) To raise the telescopic shaft, pull (separate)
both the top and bottom collars apart (See
Fig. D1), and pull (raise) the bottom section
of the shaft up to the desired height. It will
click into nay one of the notches on the
shaft, and lock into place.
2) Release both collars to lock the shaft into
place (See Fig. D2).
3) To lower or collapse the shaft simply pull
the bottom collar down and lower the shaft.
5. ADJUST THE CUTTING ANGLE
(See Fig. E)
Your trimmer has a 4-position tilting head that
easily adjusts to the desired working angle
for optimum operator control and comfort. To
adjust the trimmer head angle:
1) Disconnect the trimmer from the power
supply.
WARNING: To avoid injury, ALWAYS
turn off and disconnect the trimmer
from the power outlet BEFORE installing
parts or cleaning the trimmer or making
any adjustments.
2) Press the trimmer head adjustment button
on the motor housing (See Fig. E).
3) Move the trimmer head to one of four
different angles and release the button.
Head will click into position. Easily readjust
the angle to a more comfortable or efficient
position as needed.
WARNING: BEFORE connecting
your trimmer to the power outlet,
BE SURE you are not pressing in on the
trigger switch. Failure to do so could
result in accidental start-up, which may
cause serious personal injury.
6. ROTATE REAR HANDLE AND UPPER
SHAFT 180° (See Fig. F1, F2)
1) Disconnect the trimmer from the power
supply.
2) To rotate the top shaft 180
o
, pull (separate)
both the top and bottom collars apart (See
Fig.F1), and rotate the top shaft with rear
handle (and auxiliary handle) 180°.Release
both collars and shaft will lock in place.
3) Your trimmer is ready for use as an edger
(See Figs.F1, F2).
7. SELECT AN EXTENSION CORD
WARNING! Use only a voltage supply as
specified on your unit.
Extension Cord Gauge Cord
Length of Cord Gauge
25 Ft. (7.5m) 18 Gauge
50 Ft. (15m) 16 Gauge
100 Ft. (30m) 16 Gauge
Extension cords are available for this unit.
8. PIGTAIL POWER CORD
(See Fig. G1, G2)
Your trimmer/edger has a 12-inch pigtail
power cord. This cord must be attached to
a proper extension cord. Make a loop in the
extension cord. Push loop through hole in the
handle (See Fig. G1). Fasten loop around cord
retention hook. Plug trimmer’s power cord into
extension cord plug (See Fig. G2).
OPERATION INSTRuCTIONS
1. ON/OFF TRIGGER (See Fig. H)
Press and hold the trigger to operate the
trimmer. Release to stop
WARNING: The cutting head continues
to rotate after the trimmer has been
switched off. Wait until it stops before laying
the trimmer down.
