EN - 7

E. Led light

F. Handle pivot closure

G. Central handle

H. Ignition key

I. Exhaust chute

J.

K. Auger

L. Auger compartment

M. Wheel

N. Lower blade

O. Transport handle

P. Battery compartment

Q.

R.

Battery charger (supplied separately)

Battery (supplied separately)

4. ASSEMBLY

For storage and transport purposes, some

components of the machine are not installed

in the factory and have to be assembled after

unpacking. Follow the instructions below.

4.1 ASSEMBLY COMPONENTS

The packaging holds the components needed

for assembly

4 ) listed in the following table:

Component Fig. N.

Snow thrower 4 1

Discharge chute

adjustment handle

4.A, 4.A1,

4.A2

1

Handle 4.B 1

Handle

4.C 1

Spacers and screws for

securing the handle in place

4.D, 4.E 2

Spacers and screws for

securing the handle in place

4.F, 4.G 4

Ignition key 4.H 1

1

4.I

1

Instructions -

4.2 UNPACKING

1. Cautiously open the packaging, paying

attention not to lose components.

2. Consult the documentation in the box,

including these instructions.

3. Remove all the unassembled parts from the

box.

4. Lift the snow thrower from the box.

5. Dispose of the box and packaging in

compliance with local regulations.

4.3 HANDLE ASSEMBLY

1. Assemble the central part of the handle

4.C) on the snow thrower (lower part of

handle), fastening it with screws

4.D, 4.E)

on both sides.

2. Position the upper handle

4.B) on the

central one and fasten it with the

screws and fastenings

4.G, 4.F).

3. Fasten the electrical cable in place with the

cable gland 4.I).

4.4 DISCHARGE CHUTE ADJUSTMENT

HANDLE ASSEMBLY

1. Assemble the handle

5.A1) using the

extension shaft 5.A), fastening it

in place with a spring pin

5.A2). Ensure

the holes on the shaft and the joint are aligned.

2. Insert the spring pin in the hole and fasten.

3. Pass the handle obtained in the

lower

handle support

5.B).

4. Insert the end of the handle in the

coupling hole on the chute, keeping it straight

and with the grip upwards

5.C).

5. Check the discharge chute by turning it

entirely in both directions. The chute must

freely rotate

9 ).

4.5 DEFLECTOR ASSEMBLY

1. Insert the

on the discharge duct in

the upright position

6.A).

2. Fit the tabs on both sides in the rotation

eyelets

6.B).

3. Push until the pins

into the holes

with a click.

5. CONTROLS

5.1 IGNITION KEY

Used to start and stop the motor. The

ignition key has two positions

8.H):

1. Key removed - OFF - the motor stops and

cannot be restarted.

2. Key inserted - ON - the motor can start and

run.

5.2 STARTER LEVER

Used to start and stop the motor.
