Gespasa IRON-50 24 VDC (00011) Инструкция по эксплуатации онлайн
Partida Horta d’Amunt s/n · Apdo. de Correos nº 149
25600 BALAGUER (Lleida) · SPAIN
++34 (9)73 451 072
++34 (9)73 448 400
gespasa@gespasa.es · http://www.gespasa.es
INSTRUCTION MANUAL
WARRANTY AND CONFORMITY DECLARATION
200
160
51
128
78
100
Ø
6
149
h: 137
IRON-50 0.30 kW 12 or 24 VDC
12 VDC code 00001
24 VDC code 00011
CONNECTION: 1" · SUCTION: 2.7 m 1 1/4" · DELIVERY: 4 m 1"
IRON-50 12 VDC
S-50 12 VDC
IRON-50 24 VDC
S-50 24 VDC
PSF-040PT-60FREE PA-60
53
l/min
43
l/min
44
l/min
34
l/min
42
l/min
34
l/min
36
l/min
28
l/min
53
l/min
43
l/min
44
l/min
33
l/min
42
l/min
34
l/min
36
l/min
28
l/min
16 A
18 A 18 A
19 A
17 A
18 A
18 A
19 A
7.9 A
8.5 A 8.9 A
9.5 A
8.5 A
8.9 A 9.1 A
9.5 A
No. DESCRIPTION CODE
1 M-4x12 mm DIN.912 SCREW 805400035
2 PUMP BODY COVER 003504000
3 58x3 mm NBR JOINT 803101061
4 F-211 ROLLER 000002210
5 5-BLADE SET 000002109
6 SEGER INT.30 RING 800303012
7 PUMP FILTER 003502001
8 BY-PASS VALVE 805606102
9 PUMP BODY 003503001
10 10x26x7 mm RETAINER 804600002
11 4x4x10 mm SHAFT KEY 000002002
12a 12 VDC MOTOR 000001001
12b 24 VDC MOTOR 000101001
13 FAN 000001002
14 FAN COVER 000001003
15-24 M-5x10 DIN.912 SCREW 805400010
16 BYPASS SPRING 000001004
17 2.5 mm ISOLATED FASTON TERMINAL 807500010
18 ELECTRICAL WALL BUSHING 806403001
19-20-21 CONNECTION CABLE WITH CLAMPS 800900002
22 CONNECTION PLUG 805203001
23 BEARING PLATE COVER 000003002
25 M-5 RING 800300002
26 BEARING PLATE 000003001
27 SWITCH 807400016
11
9
5
4
3
2
20
19
18
25
27
26
24
23
22
13
14
12
10
17
21
15
1
7
8
6
16
M-232
anti-clockwise
turn sense
sentido giro
antihorario
