Installation and regulation of power tool
elements
Before carrying out any works on the power tool it
must be disconnected from the mains
Do not draw up the fastening elements
too tight to avoid damaging the thread
Additional handle (see g. 1)
Always use the additional handle 3 when operating�
Additional handle 3 may be positioned as deemed
comfortable by the user
Loose additional handle 3 as shown in g. 1.
Place additional handle 3 in desired position�
Tighten additional handle 3 as shown in g. 1.
Depth stop (see g. 2)
Use depth stop 2 to set a required drilling depth (see
g. 2).
Loose additional handle 3 as shown in g. 2.1.
Move depth stop 2 to set a required drilling depth
(see g. 2.2)
Tighten additional handle 3 as shown in g. 2.3.
Mounting / replacement of accessories
With long-term use the drill bit may be-
come very warm; use gloves to remove
it.
Gear rim chuck (see g. 3)
Release the cams grip with drill chuck key 11, then ro-
tate the quill of gear rim chuck 1 counter-clockwise with
your hand (see g. 3) until the cams move apart at the
distance allowing an accessory to be mounted / replaced�
Mount / replace an accessory
Rotate the quill of gear rim chuck 1 clockwise with
your hand in order to lock the accessory mounted� Do
not allow the accessory to become distorted�
Tighten the cams of gear rim chuck 1 with drill chuck
key 11 applying a similar torque to each of the three
openings on the side surface of the chuck�
Mounting / dismounting of the drill chuck (see
g. 4-5)
To mount the gear rim chuck 1, carry out the opera-
tions in consecutive stages as it is shown in gure 4.
To dismount the gear rim chuck 1, carry out the op-
erations in consecutive stages as it is shown in gure 5.
Attention: keep in mind that in the pro-
cess of mounting / dismounting of the
drill chuck the screw 12 has a left-hand
thread.
Screwdriver bit / magnetic holder (see g. 6)
When using the power tool as a screwdriver, use
magnetic holder 14 for reliable locking of screwdriver
bits 13 (see g. 6). A magnetic holder 14 is not needed
for extended screwdriver bits 13 (specially purposed
for screwdrivers)�
Initial operating of the power tool
Always use the correct supply voltage: the power sup-
ply voltage must match the information quoted on the
power tool identication plate.
Switching the power tool on / off
Short-term switching on / off
To switch on, press and hold on / off switch 10, to
switch off - release it�
Long-term switching on / off
Switching on:
Push on / off switch 10 and lock it in the position with
lock-on button 9
Switching off:
Push and release on / off switch 10
Design features of the power tool
"Impact / drill" switch
Switch 5 is purposed for switching between the follow-
ing operation modes of the power tool:
drilling, screwing, unscrewing - drilling without
impact in wood, synthetic materials, metal� Screwing
and unscrewing fastening components;
impact drilling - impact drilling in brick, concrete,
natural stone�
Drilling, screwing, unscrewing:
To switch to this operation mode, turn
switch 5 so that the drilling sign coincides
with the mark on the body
Impact drilling:
To switch to this operation mode, turn
switch 5 so that the Impact drilling sign coin-
cides with the mark on the body
One can switch to another operation mode without
stopping the power tool, simply decrease pressure
applied to it to some extent.
Stepless speed adjustment
Speed is controlled from 0 to maximum by
pressing force of on / off switch 10� Weak
pressing results in low revolutions, which
enable a smooth power tool switch-on�
Speed selector thumbwheel
Use speed control 8 to set required revolutions and
impact frequency
