Makita DTW181Z [7/56] Changing the impact force

7 ENGLISH

NOTE:Toconrmthelampstatus,pullthetrigger.

Whenthelamplightsupbypullingtheswitchtrigger,

the lamp status is ON. When the lamp does not come

on, the lamp status is OFF.

NOTE:Whenthetoolisoverheated,thelightashes

foroneminute,andthentheLEDdisplaygoesoff.In

this case, cool down the tool before operating again.

NOTE:Useadryclothtowipethedirtoffthelensof

CAUTION: Use the reversing switch only after

the tool comes to a complete stop. Changing the

directionofrotationbeforethetoolstopsmaydam-

age the tool.

CAUTION: When not operating the tool,

always set the reversing switch lever to the neu-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

This allows a tightening suitable to the work.

Everytimethebuttonispressed,thenumberofblows

changes in three steps.

ThefunctionofReverserotationautostopmodeworksonlywithpullingthetriggerfullyincounterclockwisetool

rotation. When the bolt/nut gets enough loosened, the tool stops the impact and rotation.

Forapproximatelyoneminuteafterreleasingtheswitchtrigger,theimpactforcecanbechanged.

Hard

Assembling steel frames.

bolt.

Reverse rotation auto stop

mode

function.

Disassembling bolts/nuts.

NOTE:Reverserotationautostopmodeisavailableonlywhenthetoolrotatescounterclockwise.Whenrotating

clockwise in Reverse rotation auto stop mode, the impact force and speed are the same as Hard impact mode.

NOTE:Whenalllampsontheswitchpanelgoout,thetoolisturnedofftosavethebatterypower.Theimpactforce

gradecanbecheckedbypullingtheswitchtriggertotheextentthatthetooldoesnotoperate.
