18 19
user manual
EN
GFX 200/GFX 300/GFX 360/GFX 360
3
user manual
EN
GFX 200/GFX 300/GFX 360/GFX 360
3
CROSS
LINE LASER
CROSS
LINE LASER
7.2. Check of vertical line
Use a plumb bob as a reference of a vertical line. Put the laser level at
1.5m distance from the plumb bob.
1. Move the switch bar on position ON, and align vertical laser line
with the low point of plumb bob.
2. If deviation between the laser line and the plumb line exceeds 0,3
mm per 1m of plumb bob length (for a 2.5m plumb bob deviation
shouldn’t exceed 0.7 mm) – please contact the service center.
8. CARE AND MAINTENANCE
Attention! This laser level is a precise optic-mechanical device and
requires careful handling. Before starting work, as well as after
mechanical influences (falling, bumps), check the accuracy of the
device.
Observation of the following recommendations will extend the life
of the device:
- Store the device, spare parts and accessories away from children and
unauthorized people.
- Transport the device with locked compensator only.
- Protect the device from bumps, falls, and excessive vibration; do
not let moisture, construction dust and foreign objects get inside the
device.
- In case moisture gets inside the device, first of all, remove the
batteries and then contact the service center.
- Do not store or use the device for a long time in high humidity
conditions.
- Check the accuracy of the device occasionally (check the paragraph
«Accuracy check»).
- Clean the device with a soft wet cloth. Do not use harsh chemicals,
cleaning solvents or cleaning agents.
- Wipe the laser aperture with a soft lint-free cloth and isopropyl
alcohol.
- Remove the Li-ion battery or alkaline batteries from the device
before connecting the charger, otherwise the device may fail.
1.5m
