![Avaya 3631 Инструкция по эксплуатации онлайн [10/31] 5759](/views2/1006377/page10/bga.png)
3631 Wireless Telephone Administrator Guide 10
Regulatory Domain/Country WTREGDOM Value
Italy IT
Japan JP
Liechtenstein LI
Luxembourg LU
Mexico MX
Netherlands NL
New Zealand NZ
Norway NO
Portugal PT
Russia RU
Singapore SG
South Korea KR
Spain ES
Sweden SE
Switzerland CH
Taiwan TW
United Kingdom
GB
United States
US
• WTRATE—the data rate used by the 3631 telephone over the wireless link
• WTRTS—the RTS threshold used by the 3631 telephone. The default value is 3000.
• WTFRAG—the fragmentation threshold used by the 3631 telephone. The default
value is 3000.
• DNSSRVRP2—the IP address of the DNS server used with the second Access Profile.
The default value is 0.0.0.0
• DNSSRVRP3—the IP address of the DNS server used with the third Access Profile.
The default value is 0.0.0.0
• DOMAINP2—the domain name used with the second Access Profile. The default
value is null (“”).
• DOMAINP3—the domain name used with the third Access Profile. The default
value is null (“”).
