AXISM1004–WNetworkCamera
TechnicalSpecications
Function/group
Item
Specications
Included
accessories
Powersupply,standandclamp,InstallationGuide,InstallationandManagement
SoftwareCD,Windowsdecoder1-userlicense
Video
management
software
AXISCameraCompanion(included)
AXISCameraStationandvideomanagementsoftwarefromAxis’Application
DevelopmentPartners(notincluded)
Formoreinformation,seewww.axis.com/products/video/software
Optional
accessories
PoEActiveSplitter
InstallationDisplay
NetworkI/O
Connectors
I/Oterminalconnector
4–pinterminalblockfor:
•DigitalInput
•DigitalOutput
•Auxiliarypowerandground(GND)
4 3 2 1
FunctionPinNotes
Specications
GND
1
Ground
3.3VDCPower
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
Maxload=50mA
DigitalInput
3
ConnecttoGNDtoactivate,orleaveoating(unconnected)
todeactivate.
0to+40VDC
DigitalOutput
4
Internalconnectiontogroundwhenactivated,oating
(unconnected)whendeactivated.Ifusedwithaninductive
load,e.g.arelay,adiodemustbeconnectedinparallelwith
theload,forprotectionagainstvoltagetransients.
Maxload=100mA
Maxvoltage=+40VDC
3.3 V max 50 mA
1
2
3
4
58
