Manual surface grinding machine parts
Serial number
Name
Serial number
1
Foot plate
45
2
Foot screws
46
3
The bed
47
4
Lifting ring
48
5
Oil separator
49
6
Flat mat
50
7
Spring washer
51
8
Inner six angle screw
52
9
Inner six angle screw
53
10
Spring washer
54
11
Bevel gear seat
55
12
Bevel gear
56
13
Screw nut
57
14
The pipe joint
58
15
The transverse wire rod seat
59
16
Flat mat
60
17
Spring washer
61
18
Inner six angle screw
62
19
Lifting screw
63
20
Inner six angle screw
64
21
Spring washer
65
22
Flat mat
66
23
The screw rod is connected with
the sleeve seat
67
24
Column
68
25
Fixed screw
69
26
After the shell
70
27
Fixed screw
71
28
Inner six angle screw
72
29
Spring washer
73
30
Flat mat
74
31
motor
75
32
Grinding plate
76
33
Flat mat
77
34
Spring washer
78
35
Inner six angle screw
79
36
Column cap
80

Содержание

Похожие устройства

VISPROM СТАНКИ И ИНСТРУМЕНТЫ Manual surface grinding machine parts Name Serial number Name Serial number 1 Footplate 45 Large panel 2 Foot screws 46 Panel screw 3 The bed 47 Buffer cross 4 Lifting ring 48 Coupling 5 Oil separator 49 grinding wheel spindle 6 Flat mat 50 Spindle screw 7 Spring washer 51 Grinding wheel cover 8 Inner six angle screw 52 Fixed star handle 9 Inner six angle screw 53 water retaining cover 10 Spring washer 54 The small bevel gear 11 Bevel gear seat 55 bearing 12 Bevel gear 56 Transverse handle seat 13 Screw nut 57 The horizontal axis 14 The pipe joint 58 The hand wheel 15 The transverse wire rod seat 59 Handle 16 Flat mat 60 Oblique seat screw 17 Spring washer 61 Inclined bearing seat 18 Inner six angle screw 62 Dragging plate 19 Lifting screw 63 Steel rail 20 Inner six angle screw 64 Collision block 21 Spring washer 65 Collision block seat 22 Flat mat 66 Collision block retaining screw 23 The screw rod is connected with the sleeve seat 67 Synchronous belt adjusting nut 24 Column 68 Flat mat 25 Fixed screw 69 Synchronous belt adjusting screw 26 After the shell 70 Synchronous belt wheel bracket 27 Fixed screw 71 Synchronous belt wheel 28 Inner six angle screw 72 Synchronous belt 29 Spring washer 73 Synchronous belt fixing plate 30 Flat mat 74 Synchronous belt holder 31 motor 75 Rail steel 32 Grinding plate 76 The dustproof cover retaining screw 33 Flat mat 77 The dustproof cover fixed flat pad 34 Spring washer 78 Dust cover 35 Inner six angle screw 79 Synchronous belt fixed screw 36 Column cap 80 workbench 29
