Viper LSU135-EU (50000110) [8/72] Dry operation

Viper LSU135-EU (50000110) [8/72] Dry operation
condition.
in a clean and dry
emptied of any liquid before using for dry pick-up and that the cloth filter is
that the container is
he use of absorbing dirt filter assembly must be used. Always ensure
INTRODUCTION
This manual will help you get the most from VIPER wet & dry vacuum cleaner.
Read it thoroughly before operating the machine.
This is a wet and dry vacuum cleaner machine,used for water suction and dust suction on the
floor.It is recommended for commercial use.
MACHINE STRUCTURE DESCRIPTION
LSU135 Structure Description Refer to page Three”F1”
1.Power Cord 2.Machine Head Handle 3.Power Switch 4.Machine Head Assembly 5.Float
Cup 6.Absorbing Dirt Filter Assembly 7.Crevice Tool 8.Dusting Tool 9.Soft Absorbing Tube
10.Absorb Tube Base Pressing Button 11.Absorb Tube Base 12.Tank Catch 13.Extension Iron
Tube 14.Tank 15.Tank Bottom Base 16.Caster 17.Ground Chain 18.Dry Pick-up Tool 19.Wet
Pick-up Tool 20.Power Cord Storage Hanger
LSU155/LSU255/LSU275/LSU375/LSU395 (Refer to page Four”F2”
1.Power Cord 2.Machine Head Handle 3.Power Switch 4. Foam Guard 5.Power Cord Storage
Hanger 6.Machine Head Assembly 7.Float Cup Bracket 8.Absorbing Dust Filter Assembly
9.Bottom Base Handle 10.Tank Catch 11.Tank Handle Lift 12.Absorb Tube Press
Button13.Absorb Tube Base 14.Rear Wheel 15.Caster 16.Tank Bottom Base 17.Drain Hose
18.Drain Hose Clamp 19.Drain Hose Block Head 20.Crevice Tool 21.Dusting Tool
22.Extension Iron Tube 23.Dry Pick-up Tool24.Wet Pick-up Tool 25. Soft Absorb Tube 26.
Tank
Operation Instructions
Dry Operation
T
When the machine suction force is reducing or machine noise is becoming bigger. Switch off
the machine and remove the power cord plug, loosen tank catch of tank‘s sides, take down
machine head assembly. Shake and clean the absorbing filter assembly .This should be done
while the hose is still connected to avoid dust exiting from the open dirt container connection.
Having shaken the filter, allow a few moments for the dust to settle. Remove absorbing dust
filter assembly from machine and empty container. If the filter’s surface appears to be heavily
English Wet And Dry Vacuum Cleaner
