![SPECK Pumpen P55/26-800 [47/68] Ancillaries](/img/pdf.png)
SPECK Pumpen P55/26-800 [47/68] Ancillaries
![SPECK Pumpen P55/26-800 [47/68] Ancillaries](/views2/1644975/page47/bg2f.png)
SIPHON INJECTORS • ANCILLARIES • PRESSURE SWITCHES • FILTERS • COUPLINGS • SWIVELS • TOOLS
www.speck.co.uk tel: 01494 523203 Page 43
Ancillaries
PUMPS • UNLOADERS • GUNS • LANCES • ACCESSORIES
Thermal Protector Valve
Use with gravity or pressure fed systems only.
Rated Pressure 10 Bar 145 psi
Part No Inlet Outlet Price
60.0630.00 1/4" M BSP 7mm Hose Barb £13.00
60.0630.50 3/8" M BSP 7mm Hose Barb £13.00
60.0630.70 1/2" M BSP 7mm Hose Barb £13.00
Thermostat with probe housing
Voltage Max 240 V
Current Max 15A
Part No Coil Length Temp Max Probe Size Price
99.069 900 mm 120°C 6.5 x 95 mm £31.50
Flow Regulator
Rated Pressure 250 Bar 3625 psi
Min Pressure 40 Bar 280 psi
Rated Flow 30 l/min 6.6 gpm
Rated Temperature 160°C 320°F
Part No Inlet Outlet Price
12.325 1/4" M BSP 1/4" F BSP £26.50
Flow Switch FL3
Rated Voltage 12 - 230 V AC/DC
Cable Length 1250mm 49.2 ins
Max Current 3 A
Max Power 60 VA
Rated Pressure 250 Bar 3625 psi
Rated Flow V 3 - 30 l/min 0.7 - 6.6 gpm
Rated Flow H 3 - 30 l/min 0.7 - 6.6 gpm
Rated Temperature 50°C 122°F
Part No Inlet Outlet Price
28.0500.10 3/8" M BSP 3/8" M BSP £32.00
Flow Switch FL7
Rated Voltage 12 - 230 V AC/DC
Cable Length 1250mm 49.2 ins
Max Current 3 A
Max Power 60 VA
Rated Pressure 350 Bar 5100 psi
Rated Flow V* 9 - 60 l/min 2 - 13.2 gpm
Rated Flow H* 6 - 60 l/min 4.5 - 13.2 gpm
Rated Temperature 50°C 122°F
Part No Inlet Outlet Price
28.0400.10 3/8" F BSP 3/8" F BSP £54.50
*When fitted on suction side of pump max flow is 30l/min - 6.6gpm
