For high speeds (H), move the switch (6) forward.

Use this mode for adjusting screws or drilling large

diameter holes.

For low speeds (L), move the switch (6) backward.

Use this mode for drilling speeds to make small

diameter holes.

Selecting the rotational direction

Change the rotational direction only

after the motor comes to a complete

stop. Otherwise, it could damage the

power tool.

Clockwise rotation (drilling, screw extraction) Set

the rotational direction selector switch (8) to the

left (Fig. 4).

Counter-clockwise rotation (screw extraction) Set

the rotational direction selector switch (8) to the

right (Fig. 4).

Deceleration

Deceleration stops the quick change chuck (1) im

mediately after the power tool has been switched

off. This helps prevent excessive tightening of the

bolts and screws and prevents damage to the work

attachments, the screwdriver bits and the slots on the

setting elements.

11. OPERATIONAL TIPS

Boring and drilling (Fig. 8-9)

• Grease the bits periodically when drilling holes in

metals (except when drilling non-ferrous metals and

their alloys).

• When drilling hard metals, apply more force to the

power tool and lower the rotation speed.

• When drilling large diameter holes in metal, first drill

a smaller diameter hole and expand it to the required

diameter (Fig. 8).

• Follow these instructions to avoid surfaces from

cracking at the tool bit's exit point when drilling holes

in the wood, as shown in (Fig. 9).

• Take the following measures to reduce dust from

drilling holes in walls and ceilings, as indicated in

(Figs. 5-6).

How to screw in screws (Fig. 7)

• First drill a hole with a diameter equal to 2/3 of the

screw’s diameter to make it easier to tighten the screws

and prevent work attachment breakage.

• Take the following measures to make a durable,

uncracked, unfractured, even joint, if you join work

pieces using screws, as shown in (Fig. 7)

12. POWER TOOL MAINTENANCE / PREVEN-

TATIVE MEASURES

Before carrying out any procedure, centre the rota-

tional direction selector switch (8) to lock the switch

and prevent the tool's untimely start-up.

Battery maintenance instructions

• Carry out charging in a timely manner, before the

battery is completely drained. Stop operating when it

is at low power and charge it immediately.

• Do not overcharge the battery when the battery is fu

lly charged, otherwise its service life will be shortened.

• Charge the battery at room temperatures of 10ºC

to 40ºC (50ºF to 104ºF).

• Charge the battery every 6 months, if you have not

used the tool for an extended period.

• Replace used batteries in a timely fashion. Decreased

working time indicates that the battery is worn out

and needs to be replaced. Take into account that the

battery can be drain faster if the work is carried out

at temperatures below 0°C.

• If unused and stored for an extended period, the

machine should be stored at room temperature,

without the battery and with the battery charged.

Cleaning the power tool

Keeping the power tool clean is a crucial condition for a

long-term, safe usage. Clean the tool with compressed

air frequently through the ventilation slots (9).

13. HOW TO TRANSPORT POWER TOOLS

• Do not drop the tool to avoid blows that may

damage the tool.

• Always transport the tool in its original transport case.

Li-Ion batteries

The built-in Li-Ion battery is subject to the requirements

of the legislation on dangerous goods

The user can transport the batteries by road without

any additional requirements.

When transported by third parties (e.g. air transport

or carrier agency), the special packaging and labelling

requirements must be observed.

It is necessary to consult a hazardous materials expert

to prepare the item that is to be shipped.

Only send batteries when the housing is in good

condition. Tape or cover the open contacts and pack

the battery in such a way that it cannot move in the

packaging. Keep in mind that national regulations

might be more detailed.

14. NOISE AND VIBRATION LEVEL

The noise and vibration levels of this device have

been measured in accordance with European
