Technical information

Explosion drawing and parts list

CO49K (4900500) CO49K AUTOMATIC SLITTER | Version G (From serial number 1153)

Pos. Serial No. Code Description Quantity

85 4988111 O-RING D.35 2

86 1688015 RETAINING RING D.12 1

87 4945300 CUTTING SELECTOR ASS'Y 1

88 6375052 HEX. SOCKET SET SCREW M.6X8 1

89 3380038 WASHER D.12.1X20X0.5 1

90 8569040 MICROSWITCH 1

91 4919231 LABEL 1

92 8519197 VOLTAGE LABEL 1

93 4933135 STRIP EXIT RAMP 1

94 7278014 SCREW M.4X8 2

95 4933136 MICROSWITCH HOLDER 1

96 6478001 SCREW M.4X8 PH. 2

97 3580010 WASHER D.3.2X7X0.5 2

98 8570056 SCREW 4X3/4 PH. B. 2

99 4926127 SPRING 1

100 4380014 WASHER D.6.3X11.8X0.8 1

101 7088010 RETAINING RING D.5 1

102 4945352 FENCE SUPPORT 1

103 4475024 HEX. SOCKET FLAT HD. SCREW M.5X10 3

104 7085008 HEX. NUT M.5 4

105 2973025 ALLEN SCREW M.5X15 1

106 4945306 FENCE ASS'Y 1

107 1380024 WASHER 8.2X19X0.1 1

108 4968250 FASTON 1

109 7480032 WASHER 6.4X15X2 1

110 1025101 KNOB M6X17 mm (CP) 1

111 4922323 ROLLER SPACER 2

112 6388049 RETAINING RING D.35 2

113 4983020 WASHER D.10.5 2

114 4933147 PROTECTOR 1

115 1622631 BLOCK 2
