23
TABLE OF MATERIALS
Ref. Component Material
1 Pump body
Stainless steel
Europe: EN10088-1 X5CrNi18-10 (1.4301) USA: AISI 304
2 Motor casing Die-cast aluminium
3 Impeller Fibreglass reinforced PPO
4 Diffuser Fibreglass reinforced PPO
5 Wear ring PTFE
6 Shaft (hydraulic part)
Stainless steel
Europe: EN10088-1 X5CrNi18-10 (1.4301) USA: AISI 304
7 Inlet / outlet caps
Stainless steel
Europe: EN10088-1 X8CrNiS18-9 (1.4305) USA: AISI 303
8 Mechanical seal
Carbon graphite / NBR / SS
Europe: EN10088-1 X5CrNi18-10 (1.4301) USA: AISI 304
9 Counterface Ceramic / NBR
10 Gaskets NBR 70 Shore A
11 Seal holder plate Fibreglass reinforced PPO
12 Self-priming valve Fibreglass reinforced PPO
NOCCHI
SELFPRIMING CENTRIFUGAL MULTISTAGE ELECTRIC PUMPS
Multi EVO-A
DESIGN FEATURES
1
2
3
4
5
6
7
10
10
10
11
8
9
12
