29
NOCCHI
SELFPRIMING CENTRIFUGAL MULTISTAGE ELECTRIC PUMPS
Multi EVO-A 8
PERFORMANCE TABLE
MODEL
Nominal
power (P2)
Absorbed
power (P1)
Voltage
(V)
In
(A)
μF Q
l/min 40 50 60 80 100 120 140 160 180 200
HP kW HP kW m
3
/h 2,4 3 3,6 4,8 6 7,2 8,4 9,6 10,8 12
Multi EVO-A 8-40 M 1,6 1,2 2,23 1,66 1 ~ 230 7,7 31,5
46 46 45 42 40 36 30 24 17 9
Multi EVO-A 8-40 T 1,6 1,18 2 1,5 3 ~ 230/400 5 - 2,95 ---
Multi EVO-A 8-50 M 1,9 1,4 2,7 2 1 ~ 230 9 35
56,5 55 54 51 47 42 36 28 21 12
Multi EVO-A 8-50 T 1,9 1,4 2,6 1,95 3 ~ 230/400 6,7 - 4 ---
MODEL
Dimensions mm.
Weight
(Kg)
A B C D E F G DNA DNM
Multi EVO-A 8-40 M 125 457 100 215 203 187 164 1" 1/4 1” 1/4 13,5
Multi EVO-A 8-40 T 125 457 100 215 177 187 164 1" 1/4 1” 1/4 13,5
Multi EVO-A 8-50 M 125 457 100 215 203 187 164 1" 1/4 1” 1/4 14,5
Multi EVO-A 8-50 T 125 457 100 215 177 187 164 1" 1/4 1” 1/4 14,5
OVERALL DIMENSIONS AND WEIGHTS
total head
in metres water column
F
D
C
E
B
DNM
DNA
G
A
G 1/4
-HEX 19
G 1/4
-HEX 19
