TERROVA 80
80 LBS THRUST - 24 VOLT - 45”/54”/60”/72” SHAFT
ITEM QTY
PART
NUMBER
DESCRIPTION
1 1 2777000 24V MOTOR 45” FW
1 2777001 24V MOTOR 54” FW
1 2777002 24V MOTOR 60” FW
1 2777005 24V MOTOR US2 45”
1 2777003 24V MOTOR US2 54”
1 2777004 24V MOTOR US2 60”
1 2777013 24V MOTOR US2 72”
5 1 2-100-214 ARMATURE ASSEMBLY
10 1 140-010 BEARING
15 1 788-040 RETAINING RING
20 INCLUDED IN #200 ASSY
25 1 2-300-170 BRUSH END HSING ASSY
30 1 421-276 PLAIN END HSING ASSY STD
1 9421-284 PLAIN END HOUSING US2 45”
1 9421-285 PLAIN END HOUSING US2 54”
1 9421-286 PLAIN END HOUSING US2 60”
1 9421-291 PLAIN END HOUSING US2 72”
35 1 144-017 FLANGE BEARING
40 2 880-025 SEAL
50 2 188-094 BRUSH
60 1 2-600-193 BRUSH PLATE ASSEMBLY 45”
2-600-192 BRUSH PLATE ASSEMBLY 54”
2-600-199 BRUSH PLATE ASSEMBLY 60”
65 2 975-041 BRUSH SPRING
70 2 701-043 MOTOR O-RING
80 2 701-009 O-RING — THRU-BOLT
85 2 830-027 SCREW, 10-32 X 2
90 2 830-094 THRU-BOLT
2 830-095 THRU-BOLT SONAR ONLY
95 2 990-051 WASHER — STEEL
100 2 990-052 WASHER — NYLATRON
110 2 973-025 SPACER — BRUSH PLATE
115 2 992-010 WASHER — BELLEVILLE
120 1 990-045 SPACER — THRUST
125 1 582-013 CLIP, RETAINING, SHORT
135 1 640-013 LEADWIRE — BLACK 45”
1 640-017 LEADWIRE — BLACK 54”
1 640-025 LEADWIRE — BLACK 60”
1 640-024 LEADWIRE — BLACK 72”
136 1 640-117 LEADWIRE — RED 45”
1 640-132 LEADWIRE — RED 54”
1 640-133 LEADWIRE — RED 60”
1 640-125 LEADWIRE — RED 72”
137 1 640-315 GROUNDWIRE — BROWN, US2 ONLY 45”
1 640-316 GROUNDWIRE — BROWN, US2 ONLY 54”
1 640-317 GROUNDWIRE — BROWN, US2 ONLY 60”/72”
200 1 2777096 COMPOSITE TUBE 60” FW
1 2777097 COMPOSITE TUBE 72” FW
205 INCLUDED IN #200 ASSY
ITEM QTY
PART
NUMBER
DESCRIPTION
210 2 2325665 DECAL — COVER
215 1 2325674 DECAL — CTRL BOX 80
1 2325675 DECAL — CTRL BOX 80 US2
1 2325676 DECAL — CTRL BOX 80 AUTOPILOT
1 2325677 DECAL — CTRL BOX 80 AUTOPILOT & US2
220 1 2320200 COVER, CTRL BOX
225 1 2324032 CTRL BOARD, COMPASS, AUTOPILOT ONLY
230 3 2302960 GROMMET — COMPASS AUTOPILOT ONLY
235 2 2065400 WIRE INSULATOR
240 1 2218200 FUSE HOLDER — US2 ONLY
241 2 2375400 SHRINK TUBE — 1/4” OD X 1 3/4”
245 3 2372100 SCREW — 8-18 X .625
250 3 2052510 CABLE CLAMP
255 1 2322500 CTRL BOX
260 1 2332102 SCREW — 10-24
265 4 2372100 SCREW — 8-18 X .625
270 1 2333101 NUT — 10-24
275 1 2224700 PLUG — CTRL BOX SMALL HOLE - US2
1 2224702 PLUG — CTRL BOX NO HOLE
1 2224704 PLUG — CTRL BOX LARGE HOLE - US2/LINK
300 1 2211415 UNIVERSAL SONAR 2 EXTENSION CABLE
305 1 2771500 DEPTH COLLAR ASSY
315 1 2260906 KNOB (INCLUDED IN #305)
320 1 2321702 WASHER (INCLUDED IN #305)
321 1 2323102 NUT (INCLUDED IN #305)
325 1 2997020 STEERING HOUSING
330 1 2326501 STEERING HOUSING TOP
335 1 2324604 O-RING, CASE SEAL
345 4 2305605 ROLL PIN 5/16
350 1 2308601 BREATHER, FILTER
355 1 2328610 CRADLE, MOTOR
370 1 2777020 MOTOR, STEERING ASSY
380 1 2302255 GEAR CLUSTER (3RD STAGE)
385 1 2302250 GEAR CLUSTER (2ND STAGE)
390 1 2302245 GEAR CLUSTER (1ST STAGE)
395 1 2302610 GEAR SHAFT (1ST STAGE)
400 1 2302620 GEAR SHAFT (3RD STAGE)
405 1 2302615 GEAR SHAFT (2ND STAGE)
410 2 2321704 WASHER — THRUST
415 1 2321515 LINER — OUTPUT TUBE
420 2 2324608 O-RING — 224
425 2 2321720 SHIM — O-RING
430 2 2327308 SEALED BALL BEARING
435 1 2322200 GEAR — OUTPUT
440 1 2324601 O-RING — OUTPUT GEAR
445 1 2322030 TUBE — OUTPUT MACHINED
450 1 2321510 COLLAR, DRIVE BOTTOM
455 1 2326506 STEERING HOUSING, BOTTOM
465 1 2322600 PIN — LATCH, ZINC PLATE
470 1 2322602 PIN — PIVOT, ZINC PLATE
475 2 2327310 BUSHING, PIVOT PIN
480 2 2321702 WASHER, FLAT .375
18 | minnkotamotors.com
©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
