n THIS ITEM IS PART OF AN ASSEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LISTED FOR VIEWING PURPOSES.
ITEM QTY
PART
NUMBER
DESCRIPTION
485 2 2263011 E-RING .375
490 2 2322702 SPRING — LATCH PIN
495 1 2323410 SCREW, 8-32 X .75
500 7 2323408 SCREW, 8-32 X 2
510 1 2090651 LEADWIRE — 10 GA
525 1 2991274 COIL CORD, US2, 45”
1 2991272 COIL CORD, US2, 54” / 60” / 72”
526 1 2325401 SHRINK TUBE — 3/4” ID X 2” W/ADHS
527 1 2307313 BEAD — FERRITE
528 1 2320710 TERMINAL AMP (T-TAB)
530 1 2320202 CAP, DUST, COIL CORD —NON-AP ONLY
535 1 2325641 DECAL, SIDEPLATE, LEFT
540 4 2323404 SCREW, 1/4-20
545 1 2321915 SIDEPLATE, LEFT
550 2 2323403 SCREW, 1/4-20 X .375
555 1 2321925 SKID, LEFT
560 2 2323422 SCREW, 10-24 X .375
565 2 2321700 WASHER, #10 SS
570 2 2322920 STAND-OFF, ALUM PLAIN
571 1 2323405 SCREW, 1/4” - 20 X 1/2” MCH SS
575 1 2323905 RAMP — 4” LEFT
580 4 2325115 PAD — RUBBER REST
585 4 2321706 WASHER, #8
590 4 2323412 SCREW, 8-18 X .25
595 2 2324705 INSERT — RAMP
600 1 2994202 RELEASE ARM ASSEMBLY
605 2 2322710 SPRING — EXTENSION
n
1 2770250 COVER — SPEED CONTROL WITH DECAL
620 1 2325650 DECAL, SPEED CONTROL
625 1 2320210 COVER, SPEED CONTROL
630 1 2322901 STRAIN RELIEF
635 1 2324019 CONTROL BOARD, 24-36V STANDARD (2 PLUGS)
1 2324023 CONTROL BOARD, 24-36V IPILOT & LINK (1 PLUG)
n
2884050 SWITCH — REED REPAIR KIT
636 1 2320208 DUST PLUG
640 1 2320203 CAP, DUST, CTRL BOARD
645 2 2323406 SCREW, 10-24 X .50 CRPH SS
650 1 2321315 HOLDER, CONNECTOR
655 2 2332103 SCREW, 6-20 X .375
660 1 2074071 BATTERY METER, 24V
665 4 2323402 SCREW, 1/4-20 X .375
670 1 2321940 BRACKET, STRAIN RELIEF
675 1 2321310 STRAIN RELIEF, WIRE
680 1 2323405 SCREW, 1/4-20 X .5
685 2 2013100 SPEED NUT, .375
690 1 2320215 HANDLE, RELEASE CVR
695 1 2301700 BUSHING, SPACER - RELEASE LEVER - BRASS
700 1 2322701 TORSION SPRING
710 1 2320400 HANDLE, RELEASE FW
715 2 2322712 RELEASE HANDLE SPRING
720 2 2322604 BUSHING, HANDLE
725 2 2332104 SCREW, 1/4-20 X .625
ITEM QTY
PART
NUMBER
DESCRIPTION
730 2 2323000 E-CLIP, 3/16, SS
735 1 2322606 PIN, FOLLOWER, HANDLE
740 1 2321905 BASE EXTRUSION, MACH
745 2 2322912 SPRING PIN,
750 1 2321950 BRACKET, SIDEPLATE
755 1 2323900 RAMP — 4” RIGHT
757 1 2994204 ARM, RELEASE, RIGHT
760 1 2321920 SKID, RIGHT
765 3 2301310 SCREW, 8-18 X .5
770 1 2320220 COVER, ACCESS, FW
775 1 2321910 SIDEPLATE, RIGHT
780 1 2325640 DECAL, SIDEPLATE, RIGHT
850 1 2994720 FOOT PEDAL
851 1 2326710 PLUG, FOOT PEDAL
860 1 2324400 PEDAL, HEEL-TOE
865 1 2322714 SPRING, MOMENTARY
870 2 2321300 CLAMP
875 4 2223430 SCREW, 8 X .75
880 1 2328600 FLEX FINGER
885 1 2323710 BUTTON, MOMENTARY, LEFT
900 1 2325660 DECAL, FOOT PEDAL
910 1 2320205 COVER, HEEL-TOE
915 1 2323725 BUTTON, AP
920 1 2323715 BUTTON, MOM/CON
925 1 2320100 KNOB, SPEED, FOOT PEDAL
930 2 2332103 SCREW, 6-20 X .375
935 1 2324021 CONTROL BOARD, FT PEDAL
936 1 2320207 DUST CAP
940 1 2322900 STRAIN RELIEF, FT PEDAL
945 1 2324500 BASE PLATE, FT PEDAL
950 10 2301310 SCREW, #8 X .5
955 1 2323730 BUTTON, STEER, LEFT
960 1 2323735 BUTTON, MOMENTARY
965 1 2323701 BUTTON, STEER, RIGHT
970 5 2322704 SPRING, FOOT PEDAL
975 1 2994859 BUMPER, BAG ASSY
980 2 2322706 SPRING, BARREL
985 2 2323420 SCREW, 8-18 X .375
990 2 2372100 SCREW, 8-18 X .625
n
1378132 PROPELLER KIT WW2
n
2994876 PROPELLER BAG ASSY
1000 1 2331160 PROPELLER WW2
1010 1 2262658 DRIVE PIN, LARGE
1015 1 2091701 WASHER, PROP, LARGE
1020 1 2093101 NUT, NYLOCK, PROP, LARGE
n
2994864 MOUNTING HARDWARE BAG ASSY
n
2889460 SEAL & ORING KIT
TERROVA 80
80 LBS THRUST - 24 VOLT - 45”/54”/60”/72” SHAFT
minnkotamotors.com | 19
©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
