FD450/ Translation of the original instructions
27) Do not allow any fuel spillage and after filling the tank wipe away any spilled fuel before
starting the engine.
28) Do not tamper with safety devices or disable them.
29) Do not change the engine settings, especially the maximum number of revs.
30) Do not rest heavy loads on the seat, the starter safety device could become disengaged.
31) Never attempt any adjustment or cleaning with the engine running.
32) Never allow anyone to check the machine while you are seated at the controls with the engine
running.
33) Do not move the machine without the deck, because it may turn over and be very dangerous.
34) Replace worn or damaged mufflers.
FURTHER SAFETY ADVICE
The above mentioned warnings could not be enough to avoid any risk, if the operator does not use
the lawnmower correctly. For your safety therefore we give you following advice:
35) The mower blade is very dangerous when rotating, never put hands or feet underneath
the mower deck.
36) Do not engage the reverse gear at full power.
37) It is dangerous to operate the steering wheel abruptly with the motor at full power.
38) Fill the tank with fuel before starting the engine. Only refuel outdoors, always turn off the
engine, keep away from sparks or naked flames, do not smoke! Always replace the cap on the
fuel tank and those on fuel containers properly.
39) If the fuel tank has to be emptied, only do so outdoors.
40) If you have children, hide the ignition key after using the machine.
41) CAUTION: to avoid the risk of fire, keep the engine compartment, muffler, discharge outlets,
battery, tank area and fuel pipes free of grass, leaves, dirt etc...
42) Do not store the machine inside any building where the engine fumes can reach naked
flames, sparks or bare electrical wires.
Remove the implements, turn off the engine and disconnect the spark plugs:
a) before cleaning obstructed points.
b) before checking or repairing the lawnmower.
c) when the machine hits a foreign body (check the mower deck to see if it is damaged
make repairs before you operate).
d) if unusual vibration occurs, stop and inspect the machine. Contact the nearest
authorized service centre if you need help.
IDENTIFICATION AND SERVICING
IDENTIFICATION
The Grillo FD450 has an ID plate showing the serial
number, located underneath the seat. Always state the
serial number when ordering spare parts or asking for
technical assistance
AFTER-SALES SERVICE
This handbook provides the instructions for using the mower. For correct servicing, contact your
local dealer.
SPARE PARTS
Original spare parts should always be used, as they are the only guarantee of safety and
interchangeability. When ordering, always state the machine's serial number and the code number
of the spare part required. For engine parts, follow the instructions provided in the specific manual.
GUARANTEE
The guarantee is given in compliance with the current law. The dealer will have to give the client a
copy of the registration card of the machine, which they will print up from the Grillo website.
For the engine the guarantee of the relative manufacturers apply.
5
