Daikin EWLP026KBW1N [3/20] Technical specifications
![Daikin EWLP030KBW1N [3/20] Technical specifications](/views2/1656544/page3/bg3.png)
EWLP012~065KBW1N
Condenserless water-cooled water chillers
4PW61666-1A – 2012.04
Operation manual
2
Technical specifications
(1)
Electrical specifications
(2)
(1) Refer to the engineering data book for the complete list of specifications.
General EWLP 012 020 026 030
Dimensions HxWxD (mm) 600x600x600
Machine weight
(kg)
104 138 144 149
Connections
• condenser
discharge
connection
(copper)
(mm)
12.7 flare 19.1 flare 19.1 flare 19.1 flare
• condenser liquid
connection
(copper)
(mm)
9.52 flare 12.7 flare 12.7 flare 12.7 flare
General EWLP 040 055 065
Dimensions HxWxD (mm) 600x600x1200
Machine weight
(kg)
252 265 274
Connections
• condenser
discharge
connection
(copper)
(mm)
2x 19.1 flare 2x 19.1 flare 2x 19.1 flare
• condenser liquid
connection
(copper)
(mm)
2x 12.7 flare 2x 12.7 flare 2x 12.7 flare
Compressor EWLP 012 020 026 030
Model JT140BF-YE JT212DA-YE JT300DA-YE JT335DA-YE
Speed
(rpm)
2900
Oil type FVC68D
Oil charge volume
(l)
1.5 2.7 2.7 2.7
Refrigerant type R407C
Evaporator
Type brased plate heat exchanger
Min. water volume
(l)
62.1 103 134 155
Water flow range
(l/min)
31~69 53~115 65~153 76~179
Condenser
refer to engeneering specifications as published by the supplier of your
remote condenser
Compressor EWLP 040 055 065
Model 2x
JT212DA-YE
2x
JT300DA-YE
2x
JT335DA-YE
Speed
(rpm)
2900
Oil type FVC68D
Oil charge volume
(l)
2x 2.7 2x 2.7 2x 2.7
Refrigerant type R407C
Evaporator
Type brased plate heat exchanger
Min. water volume
(l)
205 268 311
Water flow range
(l/min)
101~229 131~307 152~359
Condenser
refer to engeneering specifications as published by the supplier of your
remote condenser
(2) Refer to the engineering data book for the complete list of specifications.
Model EWLP 012 020 026 030
Power supply
• Phase
3N~
• Frequency
(Hz)
50
• Voltage
(V)
400
• Voltage tolerance
(%)
±10
• Recommended fuses (aM)
3x 16 3x 20 3x 25 3x 32
Compressor
• Phase
3~
• Frequency
(Hz)
50
• Voltage
(V)
400
• Nominal running current (A)
7.4 11.6 14.7 16.8
Control
• Phase
1~
• Frequency
(Hz)
50
• Voltage
(V)
230
• Recommended fuses (aM)
factory installed
Model EWLP 040 055 065
Power supply
• Phase
3N~
• Frequency
(Hz)
50
• Voltage
(V)
400
• Voltage tolerance
(%)
±10
• Recommended fuses (aM)
3x 40 3x 50 3x 50
Compressor
• Phase
3~
• Frequency
(Hz)
50
• Voltage
(V)
400
• Nominal running current (A)
11.6 14.7 16.8
Control
• Phase
1~
• Frequency
(Hz)
50
• Voltage
(V)
230
• Recommended fuses (aM)
factory installed
