BY133
THRU
EM520
Dimensions in inches and (millimeters)
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Operating and Storage Temperature Range
Typical Thermal Resistance
(Note 2)
Maximum DC Reverse Current at Rated
DC Blocking Voltage
Maximum Instantaneous Forward Voltage at 1.0A DC
BY133
EM513 EM516 EM520
Typical Junction Capacitance (Note
1
)
Maximum Average Forward Rectified Current
375"(9.5mm) lead length
at T
A
= 50 C
o
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
@ TA=25
o
C
@ TA=100
o
C
Maximum Full Load Reverse Current Average, Full
Cycle .375”(9.5mm) lead length at TL = 55
o
C
DO-41
DIA.
DIA.
.028(0.7)
.024(0.6)
1.0(25.4)
MIN.
.107(2.7)
.080(2.0)
.205(5.2)
.166(4.2)
1.0(25.4)
MIN.
1.0
30
-55 to +150
40
1.1
5.0
15
500
30
1120
1600
1600
910
1300
1300
1260
1800
1800
1400
2000
2000
Volts
Amps
UNITS
µAmps
o
C/W
pF
o
C
Volts
Volts
Amps
Volts
SYMBOL
V
RRM
V
DC
I
O
I
FSM
T
J
,T
STG
V
RMS
Rθ
JA
V
F
I
R
C
J
o
* Low cost
*Low leakage
*Low forward voltage drop
*High current capability
FEATURES
MECHANICAL DATA
*Case: Molded plastic
* Epoxy: UL 94V-0 rated flame retardant
*Lead: MIL-STD-202E, Method 208 guaranteed
*Polarity: Color band denotes cathode end
* Mounting position: Any
*Weight: 0.33 gram approx.
Note 1: Measured at 1 MHz and applied reverse voltage of 4.0 volts.
Note 2: Typical thermal resistance from junction to ambient.
TECHNICAL SPECIFICATIONS OF GENERAL PURPOSE SILICON RECTIFIER
VOLTAGE RANGE - 1300 to 2000 Volts CURRENT - 1.0 Ampere
REV-3,MAY,2017 www.dccomponents.com1
