Introduction ESIE 05-07
ii
3
1
4
5
EWLD120~540MBYNN The Daikin EWLD120~540MBYNN heat pump water chillers:
P Are designed for indoor installation.
P Are used for cooling and heating applications.
P Used refrigerant R134a.
P Are available in 9 standard sizes with nominal cooling capacities ranging from 123 kW to
546 kW and with nominal heating capacities ranging from 147 KW to 655 KW.
ERAP110~170MBYNN The Daikin ERAP110~170MBYNN Air-cooled chillers:
P Are designed for outdoor installation.
P Are used for cooling applications.
P Used refrigerant R407C.
P Are available in 3 sizes with nominal cooling capacities ranging from 114 kW to
171kW.
EWTP110~540MBYNN The Daikin EWTP110~540MBYNN head recovery chillers:
P Are designed for outdoor installation.
P Are used for cooling and heat recovery applications.
P Used refrigerant R407C.
P Are available in 9 sizes with nominal cooling capacities ranging from 107 kW to
520 kW.
P Cooling capacity during heat recovery from 97,7 Kw to 465 Kw.
P Heat recovery capacity from 116kw to 441KW.
Before starting up the
unit
Before starting up the unit for the first time, make sure it has been properly installed. See "Pre-Test
Run Checks" on page 4–3.
