Operation Range ESIE 05-07
2–6 Part 2 – Functional Description
3
1
2
4
5
1.4 Operational Range: EWWD120~540MBYNN
Operational range
in cooling mode
The illustration below shows the operational range in cooling mode of the EWWD120~540MBYNN.
FOR EWWD240/280/500/520/54
0
FOR EWWD120/180/360/440
LWE
°C
CONTINUOUS AREA
°C
LWC
waterglycol
-10 0 10 20
-4 4 7 16
60
50
44
25
40
30
20
15
Max TWC
Max TWC
PULL-DOWN AREA
LWE: Leaving Water Evaporator
LWC: Leaving Water Condenser
Pull down Area
