Daikin EWAP140MBYN [11/452] Part 0
![Daikin EWAP140MBYN [11/452] Part 0](/views2/1657065/page11/bgb.png)
ESIE 05-07 Introduction
i
3
4
5
Part 0
1Introduction
1.1 About This Manual
Target group This service manual is intended for and should only be used by qualified engineers.
Purpose of this
manual
This service manual contains all the information you need to carry out the necessary repair and
maintenance tasks for the EWAP110~540MBYNN, EWAD120~340MBYNN,
EWWD120~540MBYNN, EWLD120~540MBYNN, ERAP110~170MBYNN and
EWTP110~540MBYNN.
EWAP110~540MBYNN The Daikin EWAP110~540MBYNN air-cooled water chillers:
P Are designed for outdoor installation.
P Are used for cooling applications.
P Used refrigerant R407C.
P Are available in 9 standard sizes with nominal cooling capacities ranging from 111 kW to
541 kW.
EWAD120~340MBYNN The Daikin EWAD120~340MBYNN air-cooled water chillers:
P Are designed for outdoor installation.
P Are used for cooling applications.
P Used refrigerant R134a.
P Are available in 6 standard sizes with nominal cooling capacities ranging from 121 kW to
330 kW.
EWWD120~540MBYNN The Daikin EWWD120~540MBYNN heat pump water chillers:
P Are designed for indoor installation.
P Are used for cooling and heating applications.
P Used refrigerant R134a.
P Are available in 9 standard sizes with nominal cooling capacities ranging from 123 kW to
546 kW and with nominal heating capacities ranging from 147 KW to 655 KW.
