ESIE05-07 Procedure for software upload/download

Part 3 – Troubleshooting 3–37

4.5 Copy Software from WinLoad32 to the Software key

Optional: Carel RS Converter (software Winload + drivers: are available on intranet)

P Switch off the pCO

and remove the "expansion memory" cover with a screwdriver (see "Copy from

pCO² to the Software Key" on page 3–21/Fig. 1)

P Set the key selector on (from key to pCO

)

P Insert the key in the corresponding pin connector as shown. (see "Copy from pCO² to the Software

Key" on page 3–21/Fig. 2)

P Prepare the connection for downloading the program for WinLoad32. (see also previous chapter)

P Supply power to the pCO

(check the red LED on the key is on)

P Make the upload

P Once finished, switch off the pCO

, remove the key and put the cover in its place.

P Now the key has the program transferred from WinLoad32.
