2
Contents
This manual provides installation, setup and troubleshooting information for the control panel of the Chillers with
Frame 4000 and 3200 screw compressor.
All operational descriptions contained in this manual refer to control software ver. 10.100 and subsequent revisions.
Chiller operating characteristics and menu selections may be different from other versions of the control software.
Contact Daikin Service for software update information.
Installation precautions
Warning
Electric shock hazard. Injury to personnel or damage to equipment may occur. This equipment must be properly
grounded. Connections and service of the control panel must be performed only by personnel that are knowledgeable in
the operation of the equipment being controlled.
Caution
Static sensitive components. A static discharge while handling electronic circuit boards can cause damage to the
components. Discharge any static electrical charge by touching the bare metal inside the control panel before
performing any service work. Never unplug any cables, circuit board terminal blocks, or power plugs while
power is applied to the panel.
Temperature and humidity considerations
The controller is designed to operate within an ambient temperature range of –40°C to +65°C with a maximum relative
humidity of 95% (non-condensing).
1. General description
The control panel contains a microprocessor based controller which provides all monitoring and control functions
required for the safe, efficient operation of the Chiller. The operator can monitor all operating conditions by using the
panel’s built in 4-line by 20-character keypad/display or by using an IBM compatible computer running monitor
software release 2.0 or later. In addition to providing all normal operating controls, the controller monitors all safety
devices on the unit and takes corrective action if the chiller operates out of its normal design conditions. If a fault
condition occurs, the controller will shut-down the system and activate an alarm output. The most important operating
conditions at the time an alarm condition occurs are retained in the controller’s memory to aid in troubleshooting and
fault analysis.
The system is protected by a password scheme which only allows access by authorized personnel. A password must be
entered into the panel keypad by the operator before any configuration can be altered.
Содержание
- Contents 2
- General description 2
- Main features of control software 4
- Components description 5
- Main board 6
- Eexv valve driver 7
- Addressing of plan 8
- Alarms that will shutdown the system 8
- Meaning of the eexv driver status leds 8
- Other alarms 8
- Air cooled chillers unit config 00 9
- Analogue inputs analogue inputs n compressor 1 compressor 2 compressor 3 compressor 4 9
- Controller input output 9
- Digital inputs 9
- N compressor 1 compressor 2 compressor 3 compressor 4 9
- Analogue inputs n compressor 1 compressor 2 compressor 3 compressor 4 10
- Analogue outputs n compressor 1 compressor 2 compressor 3 compressor 4 10
- Digital inputs n compressor 1 compressor 2 compressor 3 compressor 4 10
- Digital outputs n compressor 1 compressor 2 compressor 3 compressor 4 10
- Water cooled heat pump or pursuit unit config 01 or 02 10
- Analogue outputs n compressor 1 compressor 2 compressor 3 compressor 4 11
- Digital inputs 11
- Digital outputs n compressor 1 compressor 2 compressor 3 compressor 4 11
- N compressor 1 compressor 2 compressor 3 compressor 4 11
- Water cooled chillers unit config 03 11
- Analogue inputs n compressor 1 compressor 2 compressor 3 compressor 4 12
- Analogue outputs n compressor 1 compressor 2 compressor 3 compressor 4 12
- Digital analogue outputs n compressor 1 compressor 2 compressor 3 compressor 4 12
- Display and keypad 13
- General description 13
- Gg mm aa sat hh mm 13
- Unit status cooling staging xxx stp source local 13
- Keypad keys and their functions 14
- Category description keys password 15
- Main menu 15
- User menu 16
- Input output menu i o menu 17
- Manufacturer menu 17
- Setting menu 17
- Warning 17
- Maintenance menu 18
- Alarm list 19
- Alarms menu 19
- Buffer alarm menu 19
- Service menu 19
- Description of the compressor capacity control 20
- Setting of the capacity transducer 20
- Water temperature setpoint reset 20
- Soft load 21
- Start up inhibition 21
- Start up with high evaporator water temperature 21
- Unit limitation 21
- Appendix 1 software upload to the controller 22
- Dire c t upload from a pc 22
- Upload from programming key 23
- Appendix 2 unit start up sequence 24
- In the following paragraphs the unit start up management and shutdown procedures are shown in addition to this the compressors loading and unloading strategy is shown 24
- Unit startup and compressors management 24
- Appendix 3 plan settings 27
