RATING AND CHARACTERISTIC CURVES (S1AFL THRU S1MFL)
FIG. 1
TYPICAL FORWARD CURRENT
DERATING CURVE
AVERAGE FORWARD CURRENT, (A)
0
.2
.4
.6
.8
1.0
AMBIENT TEMPERATURE, (
O
C)
0 25 50 75 100 125 150
FIG. 2
MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
8.3ms Single Half Sine-Wave
(JEDEC Method)
PEAK FORWARD SURGE CURRENT, (A)
NUMBER OF CYCLES AT 60Hz
0
1 2 4 6 8 10 20 40 60 80 100
10
20
30
40
50
FIG. 3
TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
INSTANTANEOUS FORWARD CURRENT, (A)
TJ=25
O
C
Pulse Width=300µs
1% Duty Cycle
INSTANTANEOUS FORWARD VOLTAGE, (V)
0.4
.03
0.1
0.3
3.0
10
20
1.0
.01
0.6 0.8 1.0 1.2 1.4 1.6 1.8
Single Phase
Half Wave 60Hz
Resistive or
Inductive Load
FIG. 4
TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT, (µA)
1
10
100
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
0 20 40 60 80 120 140100
.01
TJ=100
O
C
TJ=125
O
C
TJ=25
O
C
.1
REV-3,MAY,2017 www.dccomponents.com2
