MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SCHOTTKY
BARRIER
DIODES
VOLTAGE RANGE - 50 to 100 Volts CURRENT - 1.0 Ampere
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
SR150
THRU
SR1100
Dimensions in inches and (millimeters)
.034 (0.9)
.028 (0.7)
DIA.
1.0 (25.4)
MIN.
.205 (5.2)
.166 (4.2)
.107 (2.7)
.080 (2.0)
DIA.
1.0 (25.4)
MIN.
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Operating Temperature Range
UNITS
Volts
Volts
Volts
Amps
1.0
30
Amps
Storage Tmperature Range
-65 to +150
Maximum DC Reverse Current
at Rated DC Blocking Voltage
mAmps
Maximum Instantaneous Forward Voltage at IF=1.0A
1.0
Volts
0
C/W
0
C
.85.70
SR150 SR160 SR180 SR1100
50 60 80 100
35 42 56 70
50 60 80 100
.375*(9.5mm) lead length
100
Typical Junction Capacitance (Note 2) pF
110
Typical Thermal Resistance (Note 1)
50
0
C
SYMBOL
O
V
F
I
R
C
J
I
FSM
I
V
DC
V
RRM
V
RMS
R
JA
θ
T
J
T
STG
NOTES : 1. Thermal Resistance (Junction to Ambient): Vertical PC Board Mounting, 0.375”(9.5mm) Lead Length.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
-50 to +125
@T
A
= 25
o
C
@T
A
= 100
o
C
FEATURES
* Low switching noise
* Low forward voltage drop
* High current capability
* High switching capability
* High surge capability
* High relibility
* Lead: MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Mounting position: Any
* Weight: 0.33 gram
DO-41
REV-1,Apr/25/2013
