1.3 Maintenance of the Control Devices
Preventive
maintenance
A program of scheduled maintenance should be set up and followed. The items mentioned are to be
used as a guide and must be used in combination with sound electrical and refrigeration workmanship
to ensure trouble free operation and performance.
Liquid line solenoid
valve
The liquid-line solenoid-valve shuts off refrigerant flow during compressor off cycle. Normally they do
not require any maintenance. Follow the instructions below to check the liquid line solenoid valve.
■ Observe operation, there must be no temperature difference before and after the valve in flow
direction.
■ Check the electrical connection. When power is on, the coil stem should be magnetised. Check by
gently touching the top of the stem with a screwdriver.
Refrigerant
sightglass
The refrigerant sight-glass should be observed periodically. A clear glass 15 min. after start-up
indicates an adequate refrigerant charge to ensure proper feed through the expansion valve. Follow
the instructions below to check the moisture.
■ Check the moisture indicator element by comparing it with the sight-glass colour code.
■ If the moisture indicator indicates a wet environment, replace the filter dryer. The moisture indicator
must indicate dry after 10 hours of operation. If not, pump down and change the filter dryer core.
Liquid injection
solenoid valve
Liquid-injection is required during compressor operation to seal and cool the main screw. The liquid
line solenoid valve and the liquid injection solenoid valve close when the compressor is stopped. The
injection solenoid-valve stays open during pump-down. The suction pressure will rise between 0,7 and
1,2 bar. For inspection use the same method as for the liquid-line solenoid-valve.
Filter dryer Follow the instructions below to check the filter dryer.
■ A filter replacement is recommended during scheduled service maintenance or any time when
excessive pressure drop is read across the filter dryer. A partly clogged filter may cause
compressor discharge. Due to insufficient compressor cooling, the filter needs changing when wet
is indicated on the sight-glass moisture element.
■ The maximum allowed pressure drop by 70% to 100% loading is 0,7 bar and by 25% to 50%
capacity 0,3bar.
■ To change the filter dryer core, close the liquid line service valve and follow the pump-down
programme on the controller after 3 LP trips the alarm will sound the end off the pump down cycle.
Some pressure will remain on the LP side due to the liquid injection (compressor cooling cycle).
■ The remaining freon must be evaluated via the pump-out unit to the condenser.
■ Before opening the filter dryer make sure the liquid line and the filter body are warm (To avoid
condensation within the liquid line or filter core).
Flow switch and
pump interlock
Follow the instructions below to check the flow switch and the pump interlock.
■ Check operation by ohmmeter after disconnecting the wires to the field terminals and simulating
flow and no-flow conditions.
■ Inspect the flow-switch for possible corrosion (glycol applications). Check electrical connections for
shunts or bridges.
