Functional Control for a Standalone Unit ESIE05-07
2–22 Part 2 – Functional Description
3
1
2
4
5
Controller The set point menu allows setting the set-points
The user setting menu provides the ability to modify the control mode and the thermostat parameters
and can be accessed by using the password "1234"
Line n° Display Description
Default
value
Lower
limit
Upper
limit
1 INLSETP1 E Inlet water temp. set
point 1 evaporator
12.0 °C MOW+3°C 23°C
1a INLSETP1 C Inlet water temp. set
point 1 Condenser
30.0 °C 15°C 50°C
2 INLSETP2 E Inlet water temp. set
point 2 evaporator
12.0 °C MOW+3°C 23°C
2b INLSETP2 C Inlet water temp. set
point 2 Condenser
30.0 °C 15°C 50°C
3a OUTLSETP1 E Outlet water temp. set
point 1 evaporator
7.0 °C MOW 16°C
3b SETPOINT1 Thermostat setpoint
(only for ER units)
7.0 °C MOW 16°C
4a OUTLSETP2 E Outlet water temp. set
point 2 evaporator
7.0 °C MOW 16°C
4b SETPOINT2 Thermostat setpoint
(only for ER units)
7.0 °C MOW 16°C
Line n° Display Description Possible settings
1CONTROL
SETTINGS
screen title
2 MODE: to select the control
mode
MANUAL CONTROL
INL WATER STEP
OUTL WATER STEP
THERMOSTAT (ER units)
3 CIR1: CIR2: status of correspond-
ing compressor
(only for manual
mode)
0%, 30 – 100%
4a F1*: F2*: status of correspond-
ing fan speed
(only for manual
mode)
OFF / LOW / MED / HIGH for 3step
fans
0 to 100% for inverter driven fans
ESIE05-07.book Page 22 Wednesday, October 11, 2006 10:42 AM
