www.up-board.org/ www.up-shop.org /www.up-community.org
2
- Pinout
The "Android" name and the Android logo are property of Google Inc. Microsoft and Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries. Intel, the Intel logo, Intel Insider, Intel SpeedStep, and Atom are trademarks of Intel
Corporation in the U.S. and/or other countries. All rights reserved. UP Bridge The Gap is Trademark of Aaeon Europe. All Rights reserved.
Part number :
UP-APLC2-A10-0232
UP-APLC2-A10-0432
UP-APLP4-A10-0432
Intel® Celeron™ N3350 - 2 GB + 32 GB eMMC
Intel® Celeron™ N3350 - 4 GB + 32 GB eMMC
Intel® Pentium™ N4200 - 4 GB + 32 GB eMMC
UP-APLP4-A10-0864
UP-APLA4-A10-0432
Intel® Pentium™ N4200 - 8 GB + 64 GB eMMC
Intel® Atom™ E3940 - 4 GB + 32 GB eMMC
SOC
Intel® Celeron™ N3350 (up to 2.4 GHz)
Intel® Pentium™ N4200 (up to 2.5 GHz)
Intel® Atom ™ E3940 (up to 1.8Ghz)
Graphics
Intel® Gen 9 HD, supporting 4K Codec Decode and
Encode for HEVC4, H.264, VP8
Video & Audio
HDMI 1.4b x1 4K @ 30 hz + DP 1.2 4K @ 60 hz
I2S audio port
Camera interface
MIPI-CSI2 2-lane (2MP) + MIPI-CSI2 4-lane ( 8MP)
Display interface
eDP
Power
5V DC-in @ 4A-6A
Operating humidity
0% ~ 90% relative humidity, non-condensing
Operating Tempature
32-140°F / 0~60°C
Altera MAX 10 FPGA
2KLE --Celeron/ Pentium
4KLE -- ATOM
Memory
2GB ( single channel) LPDDR4
4GB/8GB ( dual channel) LPDDR4
Storage Capacity
32 GB / 64 GB / 128 GB eMMC
USB
3x UB3.0 (Type A) + 1x USB 3.0 OTG (Micro B)
2x USB2.0+2 X UART (Tx/Rx) debug port ( pin header)
Ethernet
2x Gb Ethernet (full speed, Realtek 8111G) RJ-45
RTC
Yes
Expansion
40 pin General Purpose bus + 4-channel 12-bit A/D
converter (500 ksps to 1 Msps)
60 pin EXHAT
1xmini-PCIe (full-size, auto switch to m-SATA)
M.2 2230, SATA3
Compatible Operating system
Microsoft Windows 10 (full), Windows IOT Core, Linux
(ubilinux, Ubuntu, Yocto), Android Marshmallow
Dimensions
3.37" x 3.54" / 85.60 mm × 90 mm
Certificate
CE/FCC Class A, RoHS compliant, REACH
Intel® HD Graphics
Apollo Lake
31 mm x 24 mm
HDMI + DP
Stack Connector
Dual RJ-45
Stack Connector
eMMC
16/32/64/128 GB
eMMC
1x64b
2xl2C, 2xUART
2x PWM, GPIOs
20x FPGA GPIOs
l2S, 2xSPI, SDIO
lSH-port
PWM2
USB3.0 Port 0
USB2.0 Port 0
USB3.0 Port 1, 2
USB2.0 Port 1, 2
USB3.0 Port 3
USB2.0 Port 3
PCI-E Port 0
USB2.0 Port 5 & LPC
USB2.0 Port 6, 7
UART Port 0
Fast SPI
PCI-E Port 1
PCI-E Port 2
DDI0
DDI1
CEC
eDP
with back light control
MIPI CSI2
MIPI CSI2
USB 2.0 Port 4
PCI-E Port 3
l2C l2S UART
SDIO Mux with FPGA
SATA Gen3 x1
2400 MHz LPDDR4
2/4/8 GB
Altera Max 10
HAT 40 pin
2*20 header
ADC*
Fan connector
USB 3.0 - Micro B OTG
USB Type A-1
dual stack connector
USB Type A-2
dual stack connector
Mini PCI-E
full size
10 pin header
Flash Rom
with header
Realtek 8111G
Realtek 8111G
HDMI Type A
HDMI 1.4b 3840 x 2160
DP 1.2
4096 x 2160 @ 60 hz
Hi-speed conn
41 pin
Hi-speed conn
21 pin
Hi-speed conn
31 pin
M.2 2230 E-Key
SATA600 (Port 0)
LPC, 2xl2C, DMIC, SPI
EXHAT
®
2
- Specifications
2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39
3V3
1
Ground
6
GPIO3/ UART_RTS/ SPI_2_FS1*/ ADC*_in2
11
GPIO18
16
3V3
17
GPIO19
18
GPIO6/ SPI_1_TXD
19
Ground
20
GPIO7/ SPI_1_RXD
21
GPIO22/ SPI_1_FS1
26
GPIO11
31
GPIO25/ UART_CTS/ SPI_2_FS2*
36
GPIO14
37
GPIO26/ I2S_SDI/ SPI_2_TXD*
38
Ground
39
GPIO27/ I2S_SDO/ SPI_2_CLK*
40
GPIO24/ PWM0
32
GPIO12/ PWM1
33
Ground
34
GPIO13/ I2S_WS_SYNC/ SPI_2_RXD*
35
GPIO9/ I2C0_SDA
27
GPIO23/ I2C0_SCL
28
GPIO10
29
Ground
30
GPIO20
22
GPIO8/ SPI_1_CLK
23
GPIO21/ SPI_1_FS0
24
Ground
25
GPIO17/ I2S_BCLK/ SPI_2_FS0*
12
GPIO4/ ADC*_in3
13
Ground
14
GPIO5/ ADC**_in4
15
GPIO2/ ADC*_in1
7
GPIO15/ UART_TXD
8
Ground
9
GPIO16/ UART_RXD
10
5V
2
GPIO0/ I2C1_SDA
3
5V
4
GPIO1/ I2C1_SCL
5
* 2nd SPI and ADC will be available only with E3940 SoC
