OLIMEX© 2015 A10-OLinuXino-LIME user's manual
CHAPTER 1: OVERVIEW
1. Introduction to the chapter
Thank you for choosing this OLinuXino single board computer from Olimex! This document
provides a user’s guide for the Olimex A10 LIME board. As an overview, this chapter gives the
scope of this document and lists the board’s features. The document’s organization is then detailed.
The A10-OLinuXino-LIME development board enables code development of applications running
on the A10 microcontroller, manufactured by Allwinner Technology from China.
OLinuXino is an open-source, open-hardware project and all documentation is available to the
customer.
1.1 Features
The board has the following set of features:
• A10 Cortex-A8 CPU 1GHz and Mali 400 GPU
• 512MB DDR3 RAM memory
• 4GB NAND FLASH memory (available only on the 4GB version of the board)
• Android already loaded on the NAND (available only on the 4GB version of the board)
• SATA connector with 5V SATA power jack
• Capable of HD (720p) video playback
• Native HDMI connector
• 2 x USB High-speed host with power control and current limiter
• USB-OTG with power control and current limiter
• 100MBit native Ethernet
• Battery connector with battery-charging capabilities
• LCD row of pins (0.05'' step)
• 160 GPIOs on four GPIO rows of pins (0.05'' step)
• MicroSD card connector
• DEBUG-UART connector for console debug with USB-SERIAL-CABLE-F
• GPIO LED
• Battery charge status LED
• 5V input power supply, noise immune design
• Power LED
• 2KB EEPROM for MAC address storage and more
• 3 BUTTONS with ANDROID functionality + RESET button
• 4 mount holes
• PCB dimensions: (3005×2345) mils ~ (76×59) mm
