OLIMEX© 2017 A20-OLinuXino-LIME2 user's manual
CHAPTER 1: OVERVIEW
1. Introduction to the chapter
Thank you for choosing this OLinuXino single board computer from Olimex! This document provides a
user’s guide for the Olimex A20-OLinuXino-LIME2 board. As an overview, this chapter gives the scope
of this document and lists the board’s features. The document’s organization is then detailed.
The A20-OLinuXino-LIME2 development board enables code development of applications running on
the A20 microcontroller, manufactured by Allwinner Technology from China.
OLinuXino is an open-source, open-hardware project and all design files are available to the customer.
1.1 Features
The board has the following set of features:
• A20 Cortex-A7 dual-core ARM Cortex-A7 CPU and dual-core Mali 400 GPU
• 1GB DDR3 RAM memory
• 1000MBit native Ethernet
• 4GB or 8GB NAND FLASH memory (available only on certain variants of the board)
• 4GB eMMC memory (available only on certain variants of the board)
• SATA connector with 5V SATA power jack
• Native HDMI interface with standard connector
• Capable of FullHD (1080p) video playback
• 2x USB Low-Full-High-Speed hosts with power control and current limiter
• USB-OTG with power control and current limiter
• LiPo Battery connector with battery-charging capabilities
• LCD row of pins (0.05'' step)
• 160 GPIOs on four GPIO rows of pins (0.05'' step)
• MicroSD card connector
• DEBUG-UART connector for console debug with USB-SERIAL-CABLE-F
• Status LED
• Battery charge status LED
• Power LED
• 2KB EEPROM for MAC address storage and more
• 2 BUTTONS with ANDROID functionality + RESET button
• 2 mount holes
• 5V input power supply, noise immune design
• PCB dimensions: (84 × 60)mm ~ (3.3 × 2.4)"
Page 5 of 51
