OLIMEX© 2015 A20-SOM user's manual
OLIMEX sells additional and replacement male and female 0.05'' (50 mil) step connectors. We also
have a suitable cable named CABLE-40-40-10CM.
The only power line at the GPIO connectors that might be used as input is the one named '5VEXT'.
The rest of the power signals are outputs and it would be incorrect to try to power the board from
there.
6.5.1 GPIO-1 (General Purpose Input/Output) 40pin connector
GPIO-1 connector
Pin # Signal name Processor pin Pin # Signal name Processor pin
1 +5V -POWER CIRCUIT- 2 GND -POWER CIRCUIT-
3 +3.0VA -POWER CIRCUIT- 4 AGND -POWER CIRCUIT-
5 +5V_OTG_PWR -POWER CIRCUIT- 6 LINEINR AB21
7 USB0-DRV C12 8 LINEINL AB20
9 USB0-VBUSDET C5 10 HPOUTR W19
11 USB0-IDDET B5 12 HPOUTL Y19
13 USB1-DRV A4 14 HPCOM AA19/AA20
15 USB2-DRV A5 16 MICROPHONE -MIC CIRCUIT-
17 UDP0 N21 18 MIC1OUTP AC22
19 UDM0 N20 20 MIC1OUTN AC23
21 UDP1 P21 22 MICIN2 AC21
23 UDM1 P20 24 LRADC0 AB23
25 UDP2 R21 26 LRADC1 AB22
27 UDM2 R20 28 TVIN0 AC18
29 PI0 A20 30 TVIN1 AB18
31 PI1 B20 32 TVOUT3 AB17
33 PI2 A19 34 VGA-R AC17
35 PI3 B19 36 VGA-B AB16
37 PI10 C17 38 VGA-G AC16
39 PI11 D17 40 PI14 C15
Page 25 of 41
