![OLIMEX A20-204-1G16M16GMC [29/41] Gpio 5 general purpose input output 40pin connector](/views2/1659506/page29/bg1d.png)
OLIMEX© 2015 A20-SOM user's manual
6.5.5 GPIO-5 (General Purpose Input/Output) 40pin connector
GPIO-5 connector
Pin # Signal name Processor pin# Pin # Signal name Processor pin#
1 PG0 F20 2 GND -POWER CIRCUIT-
3 PG1 F21 4 SDC3-D0 A17
5 PG2 E20 6 SDC3-D1 B17
7 PG3 D21 8 SDC3-D2 A16
9 PG4 D20 10 SDC3-D3 B16
11 PG5 C21 12 SDC3-CMD A18
13 PG6 E19 14 SDC3-CLK B18
15 PG7 C20 16 PC16/CAM-PWR-EN M21
17 PG8 D19 18 PC17/NWP F23
19 PG9 C19 20 PC18 F22
21 PG10 D18 22 PC23 G19
23 PG11 C18 24 PC24/NQS F21
25 NDQ0 H23 26 PC7/NRB1 J22
27 NDQ1 H22 28 NRB0 J23
29 NDQ2 G23 30 NRE K22
31 NDQ3 G22 32 PC3/SATA-PWR-EN L22
33 NDQ4 H21 34 NCLE L23
35 NDQ5 H20 36 NALE M22
37 NDQ6 G21 38 NWE M23
39 NDQ7 G20 40 NCE0 K23
6.5.6 GPIO-6 (General Purpose Input/Output) 10pin connector
This connector was added in hardware board revision C. It is missing in board revisions A and B.
It has some points that might be used as test pads. Also couple of signals that might be used to
debug the power supply.
GPIO-6 connector
Pin # Signal name Processor pin# Pin # Signal name Processor pin#
1 FMINL Y20 2 TVIN2 AA17
3 FMINR Y21 4 TVIN3 Y17
5 VMIC_OUT USED FOR MIC 6 AXP_BACKUP GOES TO AXP209
7 IPSOUT COMES FROM AXP209 8 AXP_RST GOES TO AXP209
9 UBOOT_SEL W8 10 AXP_PWRON GOES TO AXP209
11 VDD_RTC COMES FROM AXP209 12 GND -POWER CIRCUIT-
13 TP1 FREE 14 TP2 FREE
