OLIMEX© 2015 IMX233-OLinuXino-MAXI user's manual
1.2 The OLinuXino family
Table of comparison
OLinuXino-NANO OLinuXino-MICRO OLinuXino-MINI OLinuXino-MAXI
Processor
iMX233 @ 454Mhz iMX233 @ 454Mhz iMX233 @ 454Mhz iMX233 @ 454Mhz
Ram [MB]
64 64 64 64
# USB hosts
1 1 3 2
100/150 Mbit
Ethernet*
No/WIFI
option**
No/WIFI option** No/WIFI
option***
Yes/WIFI
option**
GPIO connector
40pins 60pins 40pins 40pins
# of buttons
3 3 2 2
Reset button
Yes Yes Yes Yes
DC power supply
5V 5V 6V-16V 6V-16V
Dimensions
3.00'' x 0.80'' 3.40'' x 1.70'' 3.70'' x 2.65'' 3.70'' x 2.65''
Breadboarding
Yes Yes No No
Audio IN
connector
No No Yes Yes
Audio OUT
connector
No No Yes Yes
UEXT connector
Yes No Yes Yes
Power jack
No**** Yes Yes Yes
VGA connector
No Yes Yes Yes
* 100Mbit Ethernet for the wired network of OLinuXino-MAXI. 150Mbit for the WIFI following
811.02n standard.
** All three boards have the option to work with MOD-WIFI_RTL8188, which is USB WIFI
modem with RTL8188CU chip and can be purchased separately. MOD-WIFI_RTL8188 can be
connected to any of the OLinuXino boards via the USB.
*** OlinuXino-MINI has additional option of having RTL8188CU hardware mounted! If you wish
RTL8188CU embedded in the device you should purchase OLinuXino-MINI-WIFI. Choosing the
embedded WIFI option will leave your USB-HOSTs available for use.
**** There is an easy access to the power pin holes, however. Especially, if you use a breadboard.
Page 6 of 59
