CSICameraConnector

TheCSICameraConnectorisa40-pinFPCconnectorwhichcanconnectexternalcameramodulewithpropersignalpin

mappings.ThepindefinitionsoftheCSIinterfaceareshownasbelow.ThisismarkedontheBananaPiboardas“CON1″.

CSIPin PinName GPIO

CON1P01 LINEINL

CON1P02 LINEINR

CON1P03 VCC-CSI

CON1P04 ADC_X1

CON1P11 GND

CON1P12 CSI-FLASH PH17

CON1P13 LRADC0

CON1P14 TWI1-SDA PB19

CON1P15 LRADC1

CON1P16 TWI1-SCK PB18

CON1P17 CSI-D0 PE4

CON1P18 CSI0-STBY-EN PH19

CON1P19 CSI0-D1 PE5

CON1P20 CSI-PCLK PE0

CON1P27 CSI-D5 PE9

CON1P28 CSI-VSYNC PE3

CON1P29 CSI-D6 PE10

CON1P30 CSI-HSYNC PE2

CON1P31 CSI-D7 PE11

CON1P32 CSI1-STBY-EN PH18

CON1P33 RESET#

CON1P34 CSI1-RESET# PH13

BPI-M1GPIOPindefine
