CON1P35 CSI-IO0 PH11

CON1P36 HPR

CON1P37 HPL

CON1P38 IPSOUT

CON1P39 GND

CON1P40 IPSOUT

LVDSspecification

LVDS(LCDdisplayinterface)

TheLVDSConnectorisa40-pinFPCconnectorwhichcanconnectexternalLCDpanel(LVDS)andtouchscreen(I2C)

moduleaswell.Thepindefinitionsofthisconnectorareshownasbelow.ThisismarkedontheBananaPiboardas

“CON2″.

LVDSPin PinName MultiplexFunctionSelect GPIO

Multi1 Multi2

CON2P01 IPSOUT(5Voutput)

CON2P02 TWI3-SDA PI1

CON2P03 IPSOUT(5Voutput)

CON2P04 TWI3-SCK PI0

CON2P05 GND

CON2P06 LCD0-IO0 PH7

CON2P07 LCDIO-03 PH12

CON2P08 LCD0-IO1 PH8

CON2P09 LCD0-D0 LVDS0-VP0 PD0

CON2P10 PWM0 PB2

CON2P11 LCD0-D1 LVDS0-VN0 PD1

CON2P12 LCD0-IO2 PH9

CON2P13 LCD0-D2 LVDS0-VP1 PD2

CON2P14 LCD0-DE PD25

CON2P15 LCD0-D3 LVDS0-VN1 PD3

CON2P16 LCD0-VSYNC PD27

CON2P17 LCD0-D4 LVDS0-VP2 PD4

CON2P18 LCD0-HSYNC PD26

CON2P19 LCD0-D5 LVDS0-VN2 PD5

CON2P20 LCD0-CS PH6

CON2P21 LCD0-D6 LVDS0-VPC PD6

CON2P22 LCD0-CLK PD24

CON2P23 LCD0-D7 LVDS0-VNC PD7

CON2P24 GND

CON2P25 LCD0-D8 LVDS0-VP3 PD8

BPI-M1GPIOPindefine
