CON2P26 LCD0-D23 PD23

CON2P27 LCD0-D9 LVDS0-VN3 PD9

CON2P28 LCD0-D22 PD22

CON2P29 LCD0-D10 PD10

CON2P30 LCD0-D21 PD21

CON2P31 LCD0-D11 PD11

CON2P32 LCD0-D20 PD20

CON2P33 LCD0-D12 PD12

CON2P40 LCD0-D16 PD16

UARTspecification:

ThejumperJ11istheUARTinterface.FordevelopersofBananaPi,thisisaneasywaytogettheUARTconsoleoutputto

checkthesystemstatusandlogmessage.

J11Pin PinName MultiplexFunctionSelect GPIO

Multi1 Multi2

J11Pin1 TXD UART0-TX PB22

J11Pin2 RXD UART0-RX PB23

ThejumperJ12providesthepowersourceincluding3.3Vand5V.ThereisapairofUARTTX/RXsignalsoutputhere.

J12Pin PinName MultiplexFunctionSelect GPIO

J12Pin6 TXD UART7_TX PI20

J12Pin7 GND

J12Pin8 GND

AllGPIOdefinelist:

BPI-M1GPIOPindefine

13
