ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–33
3
2
4
5
1
Setpoint reset
4-20mA
This screen is only visible when setpoint reset : 4-20mA is selected.
This screen allows you to set the parameters used for the 4-20mA setpoint reset (see page 2–32).
Setpoint reset
return
This screen is only visible when setpoint reset return is selected.
This screen allows you to set the parameters used for the setpoint reset (see page 2–32).
Double setpoint This screen allows you to enable/disable double setpoint.
When this function is enabled additional screen will appear in the setting menu.
Soft load This screen allows you to enable/disable the soft load function.
When soft load is enabled, Line 2 and 3 will appear.
This screen allows you to set the parameters used for the soft load function (see page 2–42).
chLWT Setpoint
Override Limits
Set. diff 3.0 ˚C
chLWT Return Reset
Start DT 03.0 ˚C
Max Reset 03.0 ˚C
Enable Double
Setpoint N/Y
Enable Soft Load Y
Max Stage 50 %
Max Time 020 min
