ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–39
3
2
4
5
1
2.4.5 Setting Menu
Operational
information
Using this menu it is possible to set and display the setpoint values.
Remark : Setting menu is only present on control board # 1.
Cooling setpoint This screen allows you to change the cooling setpoint. The setpoint can be selected between the
chilled water setpoint limits as specified in the maintenance menu.
Double setpoint This screen is only visible when the function double setpoint is enabled in the user menu.
This screen allows you to change the cooling double setpoint. The setpoint can be selected between
the chilled water setpoint limits as specified in the maintenance menu.
Actual setpoint This screen shows the actual cooling setpoint.
This actual cooling setpoint is the cooling setpoint of the unit at the moment.
This actual cooling setpoint will change if local or dual setpoint is selected or if setpoint is reset.
Key :
Password : NO
Cooling Setpoint 07.0 ˚C
Cooling Double Setpoint 04.0 ˚C
Actual Setpoint Cooling 08.5 ˚C
