General Outline ESIE07-04
1–8 Part 1 – System Outline
3
1
1
4
5
1.3 Technical Specifications: EWAD-BJYNN with OPRN
Technical
specifications
The table below contains the technical specifications.
Model EWAD-BJYNN with OPRN
Unit size 650 700 750 850 900
Cooling capacity (1) kW 606 670 730 784 868
Power input (1) kW 235 250 269 289 305
COP 2.58 2.68 2.71 2.71 2.84
Screw compressors N° 2 2 2 2 2
Refrigerant circuits N° 2 2 2 2 2
Refrigerant charge R-134a kg 97 104 114 124 128
Oil charge kg 40 40 40 40 40
Min % of capacity reduction % 12.5 12.5 12.5 12.5 12.5
Condenser fans
No. of fans / nominal power fan kW 9/1 10/1 11/1 12/1 12/1
Fan speed rpm 680 680 680 680 680
Diameter mm 800 800 800 800 800
Total air flow m3/s 36.4 40.5 44.5 48.6 48.6
Evaporator
Evaporators / water volume N°/l 1/254 1/254 1/246 1/246 1/246
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5
Water connection diameter mm 168.3 168.3 168.3 168.3 168.3
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
Weight and dimensions
Standard unit shipping weight kg 4910 4990 5256 5480 5580
Standard unit operating weight kg 5130 5200 5520 5734 5834
Unit length mm 5310 5310 6210 6210 6210
Unit width mm 2230 2230 2230 2230 2230
Unit height mm 2520 2520 2520 2520 2520
Model EWAD-BJYNN with OPRN
Unit size Note (2) 950 C10 C11 C12 C13
Cooling capacity (1) kW 945 1016 1062 1116 1175
Power input (1) kW 360 371 395 414 432
COP 2.63 2.74 2.69 2.70 2.72
Screw compressors N° 33333
Refrigerant circuits N° 33333
Refrigerant charge R-134a kg 149 160 160 180 186
Oil charge kg 60 60 60 60 60
Min % of capacity reduction % 8.3% 8.3% 8.3% 8.3% 8.3
Condenser fans
No. of fans / nominal power fan kW 14/1 16/1 16/1 18/1 18/1
Fan speed rpm 680 680 680 680 680
Diameter mm 800 800 800 800 800
Total air flow m3/s 56.7 66.0 64.8 68.8 72.9
Evaporator
Evaporators / water volume N°/l 1/415 1/415 1/402 1/402 1/402
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5
Water connection diameter mm 219.1 219.1 219.1 219.1 219.1
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
